Help CenterBBZ 4-20mA Current Signal Output RS485 Conductivity Fluid Flowmeter/ Suitable for Conductivity Fluid
Related Products
-
BBZ Digital Communication Output RS232 Rubber Liner Magnetic FlowmeterUS$ 201 - 1,039MOQ: 1 Piece -
BBZ- MFC 300 Coriolis Mass FlowmetersUS$ 120 - 960MOQ: 1 Piece
-
BBZ-SITRANS FC410 316L Stainless Steel Mass Air Flow MeterUS$ 100 - 999MOQ: 1 Piece
-
BBZ - DBE Intelligent Electromagnetic Flow MeterUS$ 85 - 1,005MOQ: 1 Piece
-
HART Output BBZ Tetrafluoroethylene Pipeline Sewage Magnetic FlowmeterUS$ 120 - 1,500MOQ: 1 Piece
Brief Introduction:
BBZ 4-20mA current signal output RS485 conductivity fluid flowmeter can output 4~20mA current signal for recording, regulating and control while meet the need of local display, and now widely used in chemical industry, environmental protection, metallurgy, pharmaceutical, paper, water supply and drainage technology and administration department.
Features:
Good accuracy and stability
Tyas well as 1-2000HZ frequency output
Digital communication output: RS485
Simple structure, solid, no moving parts, long-term life
Reliable measurement, anti-interference ability
Small size, light weight, easy installation, small maintenance
Wide measurement range, the accuracy not affected by temperature, density, pressure, viscosity, conductivity and other changes, the pressure loss is zero
Can be installed and disassembled in the case of continuous flow, convenient for users.
Lower manufacturing costs and installation costs than general electromagnetic flowmeter, especially for the flow measurement with medium and large diameter pipeline
Advanced processing technology, solid package, shock-resistant
Specifications:
|
Nominal diameter
|
Pipeline tetrafluoroethylene lining |
DN200 ~ DN2100 |
|
Pipeline rubber lining |
DN200 ~ DN1200 |
||
Flow direction |
positive ,negative and net flow |
||
Measured medium temperature |
ordinary rubber lining |
-20 ~ + 60 ℃ |
|
High temperature rubber lining |
-20 ~ + 90 ℃ |
||
PTFE lining |
-30 ~ + 100 ℃ |
||
High temperature tetrafluoroethylene lining |
-20 ~ + 180 ℃ |
||
Rated working pressure(high pressure can be customized) |
DN6-DN80 |
≤1.6MPa |
|
DN100-DN250 |
≤1.0MPa |
||
DN300-DN1200 |
≤0.6MPa |
||
Flow rate range |
0.1-15m / s |
||
Range ratio |
150:1 |
||
Accuracy |
2.0% |
||
Repeatability |
0.1% |
||
Fluid conductivity |
≥5 U S/cm |
||
Current output |
0 ~ 10mA |
0 ~ 1.5kΩ; |
|
4 ~ 20mA |
0 ~ 750 kΩ |
||
Digital frequency output |
Output frequency upper limit can be set bidirectional Output with transistor with optical isolation and open collector within 1 ~ 5000HZ. The maximum current is 250mA while external power supply ≤35V . |
||
Power supply |
AC220V, DC24V or 3.6V battery |
||
Total power consumption |
less than 20W |
||
straight pipe length |
upstream ≥5DN, downstream ≥2DN |
||
Ambient temperature |
-25~+60℃ |
||
Relative humidity |
5% ~95% |
||
Connection |
Flange |
||
Ex-proof Grade |
mdIIBT4 |
||
Protection grade |
IP68 |
||
Applications:
BBZ 4-20mA current signal output RS485 conductivity fluid flowmeter can measure the volume flow of conductive liquid as well as liquid-solid two-phase flow, high viscosity fluid and salts, acid and alkali liquid .
