Introduction:
BBZ plug in vortex flowmeter, is one of the major international flow meter products, widely used in petroleum, chemical, metallurgy and other industrial sectors, municipal construction and environmental engineering. The implementation of flow measurement, testing and control on the liquid (water, oil, petroleum, alcohol and other chemical liquids), gas ( air, water, oil, petroleum, alcohol and other chemical gases) and steam (saturated steam, superheated steam).
Features:
Unique time display and real-time data storage function, ensure to permanently store internal data;
Low total power consumption, long-term operation with a battery-powered, local display meter without external power supply ;
Reliable anti-theft feature, with password protection to prevent parameter changes;.
Specifications:
Vortex flowmeter | |
Technical index | |
Nominal diameter (mm) |
Wafer 15 to 100 mm N/A 25 to 100 mm |
Nominal pressure (MPa) |
DN15-DN200 4.0(>4.0 supply based on the agreement), DN250-DN300 1.6(>1.6 supply based on the agreement) |
Medium temperature |
Piezoelectric type:-40~260,-40~320; Capacitive type: -40~300, -40~400,-40~450( order based on the agreement) |
Noumenal materials |
1Cr18Ni9Ti,( order of other materials based on the agreement) |
Allow vibration acceleration |
Piezoelectric type:0.2g Capacitive type:1.0~2.0g |
Accuracy |
±2.5% |
Range |
1:6~1:30 |
Supply voltage |
Sensor:+12V DC,+24V DC; Transmitter:+12V DC ,+24V DC; Battery-powered type:3.6V Battery |
Output signal |
Square-wave puls( Excluding battery-powered type): High level≥5V, Low level ≤1V; Current:4~20mA |
Pressure loss coefficient |
JB/T9249 Comply with the JB/T9249 standard Cd≤2.4 |
Explosion proof sign |
Intrinsic safety type:ExdⅡia CT2-T5 Explosion proof type:ExdⅡCT2-T5 |
Protection grade |
Ordinary typeIP65 Submerged type IP68 |
Ambient conditions |
Temperature -20℃~55℃, Relative humidity 5%~90%, Atmospheric pressure:86~106kPa |
Applicable medium |
Gas, liquid, vapor |
Transmission distance |
Three-wire system pulse output type:≤300m Two-wire system standard current output type (4~20mA): Load resistance≤750Ω |
Material |
Body: Stainless steel(Special: Hastelloy, Carbon steel) |
