Help CenterBBZ- OPTIBATCH 4011 C Hygienic Coriolis Mass Flowmeter for Process Batching
Related Products
-
BBZ- OPTIMASS 1000 Water Mass FlowmeterUS$ 200 - 1,200MOQ: 1 Piece -
BBZ-OPTIMASS 3000 Mass Flowmeter for Low FlowUS$ 280 - 960MOQ: 1 Piece
-
BBZ- OPTIMASS 6000 Mass Flowmeter for Extended Temperature ApplicationsUS$ 150 - 1,530MOQ: 1 Piece
-
BBZ- OPTIMASS 7000 Wastewater Mass FlowmeterUS$ 100 - 2,000MOQ: 1 Piece
-
BBZ- Coriolis Mass Flowmeters With MFC 400 Modular Converter The High Performance Signal Converter for All ApplicationsUS$ 120 - 870MOQ: 1 Piece
Introduction:
Reliable batching repeatability
Excellent low flow stability
Hygienic design for food, beverage and pharmaceutical applications
The BBZ- OPTIBATCH 4011 C mass flowmeter for process batching as a specialised meter for batching and filling machines, has some characteristics of reliable batching repeatability, excellent low flow stability and hygienic design for food, beverage and pharmaceutical applications.
Features:
Compact design
Integrated electronics
Excellent reliability and accuracy
Hygienic design of process connections
Excellent repeatability
Stainless Steel 316L construction
CIP / SIP to maximum 120ºC / 248ºF
Welded outer casing, sealed to IP 67
Specifications:
Measuring principle |
Coriolis mass flow |
Application range |
Measurement of liquids in batching and filling machines |
Compact version |
Integral converter |
Accuracy |
±0.2% |
Stainless Steel |
0.005% of nominal flow |
Operating pressure |
1 bar / 14.5 psig |
Nominal pressure |
20°C / 68°F |
Ambient temperature |
-40~55°C (-40~131°F) |
Operating temperature |
0~100°C ( 32~212°F) |
Inlet runs |
None required |
Outlet runs |
None required |
Measuring tube |
Stainless Steel 316L (1.4404) |
Surface finish (wetted parts) |
Standard Ra 0.8 μm Optional Ra 0.5 μm |
Process connections |
Stainless Steel 316L (1.4404) |
Outer casing |
Stainless Steel 316 (1.4401), hermetically sealed as standard Optional polishing of all externals |
Power supply voltage |
24 VDC |
Power consumption |
3 W |
Power supply type |
Protected extra-low voltage (PELV) |
Pulse width |
Selectable 1 kHz or 10 kHz symmetrical pulse Factory set according to customer requirements |
Connection |
External voltage: Uext ≤ 30 VDC / ≤ 24 VAC Load rating: Imax = 20 mA |
Configuration type |
RS485 Modbus RTU |
Filling machines
Fast batching
Ultra-pure water
Food & Beverages
Chemical
Pharmaceutical industry
Cosmetics
Health Care
