Help CenterBBZ-LUGB Series Integrated Vortex Flowmeter With Temperature and Pressure Compensation
Related Products
-
BBZ-XFU-2000A-G-01- Probe Type Ultrasonic Flowmeter Fixed Clamp-on Ultrasonic FlowmeterUS$ 186 - 3,500MOQ: 1 Piece -
BBZ-XFU-2000A-C-02 Higher Accuracy Ultrasonic Flowmeter With Enhanced MonitoringUS$ 100 - 3,000MOQ: 1 Piece
-
BBZ- Daniel 3812 Liquid Ultrasonic Flowmeter BBZ-Daniel Model 3812 Two-Path Liquid Ultrasonic Flow MeterUS$ 100 - 3,000MOQ: 1 Piece
-
BBZ General Vortex Flowmeter for Steam, Gas and LiquidUS$ 100 - 1,200MOQ: 1 Piece
-
BBZ-VFD Type Vibration Vortex Flowmeter for LiquidUS$ 100 - 1,500MOQ: 1 Piece
Brief Introduction:
BBZ-LUGB vortex flowmeter is a new flow meter to measure the fluid flow in closed conduits based on Karman vortex principle. BBZ-LUGB series integrated vortex flow meters with temperature and pressure compensation are mainly used for the measurement of fluid flow in industrial pipe, such as gas ,liquid ,steam and so on. Using piezoelectric stress sensors, high reliability, BBZ-LUGB series integrated vortex flow meters with temperature and pressure compensation can work in the operating temperature range of -20 ℃ ~ 250 ℃. Analog standard signals as well as digital pulse signal output, easy supporting the use of computers and other digital systems, BBC-LUGBseries vortex flowmeter is a more advanced and an ideal alternative of the throttled flowmeter.
Applications:
BBZ-LUGB series flow meter can measure directly actual volume flow of steam, air, gas, water without temperature and pressure compensation owing to its good ability to adapt to the medium. And it can measure the standard volumetric and mass flow with temperature and pressure sensors.
Features:
Small pressure loss, large measuring range, high precision
Hardly affected by fluid density, pressure, temperature, viscosity and other parameters In the measurement of actual volume flow
No moving mechanical parts, high reliability, low maintenance.
Long-term stability
Specifications:
Measured medium |
Gas, liquid, vapor |
|
Nominal diameter(mm) |
Flange clamp |
25,32,50,80,100 |
|
Flange Connection type |
100,150,200 |
|
Flow measurement range |
Normal flow rate measurement range of Reynolds numbers 1.5 × 104 ~ 4 × 106; Gas 5 ~ 50m / s; Liquid 0.5 ~ 7m / s |
|
Nominal pressure(MPa) |
Normal temperature |
-25 ℃ ~ 100 ℃ |
High Temperature |
-25 ℃ ~ 150 ℃ /-25 ℃ ~ 250 ℃ |
|
Ambient conditions |
Ambient temperature |
-25℃~55℃ |
Humidity |
5~90% RH50℃ |
|
Body material |
Stainless steel, aluminum |
|
Allow vibration acceleration |
piezoelectric 0.2g Capacitive: 1.0 ~ 2.0g |
|
Accuracy |
± 1.0% , ± 1.5% , |
|
Supply voltage |
DC24V or lithium battery 3.6V |
|
Output signal |
Pulse voltage output signal High level 8 ~ 10V Low level 0.7 ~ 1.3V |
|
Pressure loss coefficient |
in line with JB / T9249 standard Cd≤2.4 |
|
explosion-proof signal |
Intrinsically safe ia IIc T3-T6 |
|
Protection grade |
IP65 |
|
Pulse current remote signal |
4~20 mA |
|
Transmission distance |
1000m |
|
