Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > 32-36 Core Stranded Loose Tube Armored Optical Fiber Cable

32-36 Core Stranded Loose Tube Armored Optical Fiber Cable

Name: 32-36 Core Stranded Loose Tube Armored Optical Fiber Cable
Brand: FRANKEVER
SKU: 113806465
Availability: InStock

Hangzhou Frankever Imp. & Exp. Co., Ltd.

32-36 Core Stranded Loose Tube Armored Optical Fiber Cable thumbnail-1

32-36 Core Stranded Loose Tube Armored Optical Fiber Cable photo-1

US$ 0.1 - 100 MOQ: 6 Kilometers

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

FRANKEVER

Model Number:

GYTA 32-36 cores

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name FRANKEVER

Model Number GYTA 32-36 cores

Conductor Material Other, single mode optic fiber

Insulation Material PE

Jacket PE

Number of Conductors 32-36 cores

Application Duct,Aerial

32-36 cores Stranded Loose Tube Armored optical fiber cable

structure :For the strengthening of the middle wire, PBT fiber-circular casing around package, the cable core filled ointment, with water blocking outsourcing, aluminum-plastic composite armor with wrinkles, and PE jacket.

The main mechanical properties:

	No. of fibers	unit of fiber core	Max. fibers in loose tube	OD mm	Weight kg/km	Allow tensile force long term/short term N	Allow squash Force long-term/ short-term N/100mm
GYTA 2-30 Core	2-30	5	6	9.2	85	600/1500	300/1000
GYTA 32-36 Core	32-36	6	6	10	110	600/1500	300/1000
GYTA 38-60 Core	38-60	5	12	10.8	110	600/1500	300/1000
GYTA 62-72 Core	62-72	6	12	11.8	138	600/1500	300/1000
GYTA 74-96 Core	74-96	8	12	13.6	160	600/1500	300/1000
GYTA 98-120Core	98-120	10	12	14.8	200	600/2500	300/1000
GYTA122-144 Core	122-144	12	12	17	260	600/2500	300/1000
GYTA146-216Core	146-216	18	12	17	265	600/2500	300/1000

Laying mode: Duct,Aerial

operating temperature:-40°C~+60°C

Application:Long distance and interoffice communication

features:

1.Reasonable design and precise control over the loose-tube fiber in the remainder of a long, fiber optic cable with excellent performance and temperature tensile properties.

2.Core cable filled ointment to ensure that the vertical water blocking effect.

3.Loose-tube (filled with rope) to strengthen the focus on the central pieces of SZ-cutter.

4.Double coated Aluminium tide, and has lateral pressure.

5.Loose pieces of casing around the centres of the SZ-cutter.

Wooden drum
