Frankever made in China UTP/FTP/FFTP/SFTP/SSTP CAT7 network cable

Name: Frankever made in China UTP/FTP/FFTP/SFTP/SSTP CAT7 network cable
Brand: Frankever
Availability: InStock

FOB Price

USD $230.00 - $250.00 / Carton

100 Cartons(Min.Order)

Supply Ability 10000 Carton / Cartons per Month
Port SHANGHAI OR NINGBO
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	Frankever
Model Number	HX-NWCAT60112	Type	Cat 7
Number of Conductors	4

Product Description

Product Name:

Frankever made in China UTP/FTP/FFTP/SFTP/SSTP CAT7 network cable

Specification:

UTP CAT7:

4×2×0.585mm Solid BC conductor + O.D. 1.50mm S-F-S PE insulation + AL foil shielded Twisted pairs + O.D. 7.30mm PVC/LSZH jacket

Simplex F/FTP cat7:

4×2×0.585mm Solid BC conductor + O.D. 1.50mm S-F-S PE insulation + AL foil shielded Twisted pairs + O.D. 0.4mm TC drain wire + AL foil overall screen + O.D. 7.80mm PVC/LSZH jacket

Duplex F/FTP cat7:

2×(4×2×0.585mm Solid BC conductor + O.D. 1.50mm S-F-S PE insulation + AL foil shielded Twisted pairs + O.D. 0.4mm TC drain wire + AL foil overall screen + O.D. 7.80×15.5 mm PVC/LSZH jacket)

SFTP cat7:

4×2×0.585mm Solid BC conductor + O.D. 1.50mm S-F-S PE insulation + AL foil shielded Twisted pairs + AL foil screen + 96/0.10mm TC braid screen + O.D. 8.0mm PVC/LSZH jacket

PACKING:

APPLICATION:

Technical data:

Frequency Mhz	Impedance Ohm	RL dB	Attenuation dB/100M	Next dB/100M	ELFEXT dB/100M	PS NEXT dB/100M	PS Elfext dB/100M
1	100±15	20	2.0	65.3	63.8	62.3	60.8
4	100±15	23	4.1	56.3	51.7	53.3	48.7
8	100±15	25	5.8	51.8	45.7	53.3	42.7
10	100±15	25	6.5	50.3	43.8	47.3	40.8
16	100±15	25	8.2	47.3	39.7	44.2	36.7
20	100±15	25	9.3	48.5	37.7	42.8	34.7
25	100±15	24	10.4	44.3	35.8	41.3	32.8
31.25	100±15	24	11.6	42.9	33.9	39.9	30.9
62.5	100±15	22	17.0	38.4	27.8	35.4	24.8
100	100±15	20	22.0	35.3	23.8	32.3	20.8
155	100±18	19	28.1	33.0	20.0	29.0	17.0
200	100±22	19	32.4	31.0	18.0	28.0	15.0
310	100±22	18	41.8	28.0	14.0	25.0	11.0
350	100±22	17	44.9	27.0	13.0	24.0	10.0

Incore Terms:

USD $1-$5000: EXW

USD $5001-$10000: FCA

Above USD $10000: FOB

Certification:

Factory Introduction:

Our factory, HAIYAN HUXI WIRE&CABLE CO.,LTD ,was found in 1995,we specialize in designing and manufacturing cable products for 18 years with good quality and pretty competitive price,Especially the CAR WIRING KITS,SPEAKER CABLE,RCA CABLE,HDMI CABLE etc.And we do OEM for customers with reliable quality.More infos for our company,please link: and

Workshop picture:

Question & Answer

1. What is your MOQ?

Usually our MOQ for normal spiral cable is 100 cartons, 305M in one carton.

2. How about your delivery date?

Normally our delivery date for spiral cable is about 30-35days.

3. Can you supply sample for custome

We can supply sample for customer's quality checking before placing new order to us, the delivery

cost will be charged on customer's account.

4. How about your price?

We will do our best to offer a good price for our customers, usually our price is worked out according

to the current exchange rate, probable order quantity, most important is your sincerity on cooperation!
