Portable jd Drainage Submersible Pump
US$ 20 - 50
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
UNIPOMPE
Model Number:
WQ10-13-1.8QG
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Popular Drainage Stainless Steel Submersible Pump for Dirty WaterUS$ 20 - 50MOQ: 100 Pieces -
Float Switch Submersible Pump Submersible PumpUS$ 20 - 50MOQ: 100 Pieces
-
Submersible Pump Sewage Lifting PumpUS$ 20 - 50MOQ: 100 Pieces
-
Submersible Sewage Pump/ Submersible Pump for Dirty WaterUS$ 20 - 50MOQ: 100 Pieces
-
Submersible Pump Dirty Water PumpUS$ 20 - 50MOQ: 100 Pieces
Place of Origin
Zhejiang, China
Brand Name
UNIPOMPE
Model Number
WQ10-13-1.8QG
Theory
Centrifugal Pump
Structure
Single-stage Pump
Usage
Water
Power
Electric
Standard or Nonstandard
Standard
Fuel
Other, electric
Pressure
High Pressure
Application
Sewage
Portable jd drainage submersible pump
RANGE OF PERFORMANCE
8Flow rate: up to 180L/min (10.8 m3/h)
8Head: up to 23 m
LIMITS OF USE
8Maximum immersion depth:5m
8Maximum fluid temperature 40°C
8PH value in water :4-10
8 Maximum Passage for suspended solids: 40mm
Motor
Copper winding
Built-in thermal protector
Stainless steek welded shaft
Insulation Class F
Protection Class IPχ8
WARRANTY: 1 YEAR (according to our general sales conditions)
MODEL |
POWER |
MAX.HEAD |
MAX.FLOW |
OUTLET DIA. |
CABLE |
G.W |
PACKING DIMENSION |
(Kw) |
(m) |
(L/min) |
(mm) |
(m) |
(K.g) |
(cm) |
|
WQ7-13-1.5QG |
1.5 |
23 |
180 |
40 |
6 |
31.0 |
59.0X35.5X25.0 |
WQ10-13-1.8QG |
1.8 |
21 |
180 |
50 |
6 |
34.5 |
59.0X35.5X25.0 |
8220V/50Hz, 240V/50Hz, 110V/60Hz & 240V/60Hz are available on request.
