Specifications
Solar water pump1,vortex screw and rubber stator
2,permanent Magnet Brushless motor
3,Combination of motor and controller
4SPS solar water pump,solar irrigation water pumps
Profile
Adopt stainless steel screw and rubber stator,permanet Magnet Brushless motor.With combination of motor and controller,the max efficiency is over 85%,raises 25% than the traditional AC one.
Material:
1)stainless steel casing,shaft core,coupling and pump body;copper alloy connecting ,base; rubber stator of high-strength and wear resistant.
2)Water immersion style stainless steel submersible motor;graphite bearings
Product Feature
1)Compact structure,high-lift,noiseless,pollution-free;complete electrical protecting controller device,against under-voltage,over-voltage,over-flow,over-load,waterless etc; Automatic recovery;controlling water height demand.
2)Easy installation,maintenance-free,safe and reliable
water depth:1-150m max flow:4.2m3/h
Application
1)These electric pumps series are workable within maximum head,as there are no restriction of BDC. With the adiition of high head ,high efficiency and hifh efficiency zone,they are suitable for distance water irrigation,high efficiency of increasing oxygen on aquaculture,pumping water from deep well,gardening,foutain and etc.
Working condition
1)Non-corrosive water;the volume ratio of sand content no more than 1 ‰ particle size less than 0.2mm
2)Max medium temperature up to +40°c; PH value remains 6.5-8.5
3)Work close to the rated head and must be immersed in water.
Solar Panel
Free Accessories
Motor Data
