4"(4SIM) Oil-filled Submersible Motor

Name: 4"(4SIM) Oil-filled Submersible Motor
Brand: BALLENA,UNIPOMPE
SKU: 113796529

4"(4SIM) Oil-filled Submersible Motor thumbnail-1

4"(4SIM) Oil-filled Submersible Motor photo-1

US$ 100 - 200 MOQ: 50 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

BALLENA,UNIPOMPE

Model Number:

4SIM

Contact Supplier Request Quote Chat Now

Umex (Ningbo) Imp. & Exp. Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name BALLENA,UNIPOMPE

Model Number 4SIM

Theory Centrifugal Pump

Structure Single-stage Pump

Usage Water

Power Electric

Standard or Nonstandard Standard

Fuel Gasoline

Pressure High Pressure

Application Submersible

Specifications

4 inch Submersible motor for deep well pump
1. NEMA standard.
2. oil filled motor
3. AISI 304 shaft

4" (4SIM) OIL-FILLED SUBMERSIBLE MOTOR

BASIC CHARACTERS :

8Conform to international standard of IEC34-ICE, whole blocked asynchronous motor with squirrel cage rotor.
8Outer shell, shaft and bottom made of stainless steel.
8Copper annoys or Nickel plated cast-iron upper and bracket.
8Pressure automatic adjusting device made of oil and waterproof reformed butyl rubber.
8Flange connector under the standard of NEMA.

TECHNICAL DATA:

-Pump

8Power: 1 phase - 0.37 to 2.2 KW;
8Voltage: 1 phase - 220~240V/50Hz,
8Insulation class : B
8Protection grade: IP 68
8Maximum diameter : Ö76.3mm
8Highest temperature of liquid : 35 °C.
8Minimum cooling flow along the motor: 8 cm/s
8Minimum starts per hour: 30.
8Maximum immersion depth: 80m Vertical or horizontal mounting.
8Motor protected by temperature compensated thermal relay and extra- quick trip
8Overload trip time: <10 seconds (at load is 5 times of rating current)
8Cable length: 2m (standard).

WARRANTY: 1 YEAR (according to our general sales conditions)

MODEL	Motor POWER		Capacitor 450V uF	Current Max. A	Efficiency % η	Dimensions
220V~50Hz	Motor POWER					Length(mm)	Weight(kg)
1 Phase	Kw	Hp				Length(mm)	Weight(kg)
4SIM-0.37	0.37	0.5	18	2.9	55	331	8.0
4SIM-0.55	0.55	0.75	25	4.2	58	346	8.5
4SIM-0.75	0.75	1	30	5.4	61	371	9.8
4SIM-1.1	1.1	1.5	35	7.7	64	391	10.6
4SIM-1.5	1.5	2	45	9.7	67	416	11.6
4SIM-2.2	2.2	3	70	15.6	68	441	12.6
