Specifications
Submersible Screw Pump1.Single screw instead of impellers
2.Dry type motor
3.Sandproof device
4.High head and efficiency
MAIN FEATURES:
8Single screw instead of impellers
8Oil-filled type motor
8Sandproof device
8High head and efficiency
TECHNICAL DATA:
-Pump:
8Qmax: 1.8 (m3/h)
8Total head 50 (m)
-MOTOR:
8Power: 0.25 to 0.5 kw (1 phase)
8Insulation class : B
8Protection grade: IP 68
8Maximum diameter : Ö102mm
8Highest temperature of liquid : 35 °C
8International standard: IEC 60335-1 IEC 60335-2-41.
-Application:
8For water supply from wells or reservoirs.
8For domestic use,for civil and industrial applications.
8For sprimking and flow irrigation plants.
-Operating conditions:
8Water temperature up to 35 Cent.Degree.
8Maximum sand content: 0.25%
8Minimum international diameter of well: 4''.
-Materials:
8Pump casing: AISI 304 stainless steel
8Inlet : SS304
8Screw : Steel
8Outlet : SS304
8Shaft : AISI 304 stainless steel.
8Motor casing: AISI 304 stainless steel.
8Mechanical seal: tungsten carbides.
WARRANTY: 1 YEAR (according to our general sales conditions)
MODEL |
Motor Power |
Flow |
Head |
Voltage |
Max.Dia |
Pipe.dia |
DIMENSION |
|
220-240V~50HZ |
(Kw) |
(Hp) |
m3/h |
m |
V |
mm |
inch |
cm |
1 Phase | ||||||||
EGD1-50-0.25 |
0.25 |
0.35 |
1 |
50 |
220 |
102 |
1 |
49x14x17 |
EGD1.2-50-0.37 |
0.37 |
0.5 |
1.2 |
50 |
50x14x17 |
|||
EGD1.8-50-0.50 |
0.5 |
0.7 |
1.8 |
50 |
51x14x17 |
|||
MODEL |
V&Hz |
POWER |
MAX.PUMP RATE |
MAX. HEIGHT |
MAX.DEPTH |
WORK. PRESSURE |
DIA.OF PIPE |
CABLE |
LENGTH OF CABLE |
N.W |
|
(V/Hz) |
(w) |
(l/h) |
(m) |
(m) |
(bar) |
|
|
(m) |
(kg) |
GP01600-1C |
230/50,115/60 |
600 |
3000 |
35 |
7 |
1.5-2.8 |
1'' |
H07RN-F3G1.0mm2 |
1.2 |
10.5 |
GP01800-1C |
230/50,115/60 |
800 |
3200 |
40 |
7 |
1.5-3.0 |
1'' |
H07RN-F3G1.0mm2 |
1.2 |
11.0 |
GP011000-1C |
230/50,115/60 |
1000 |
3500 |
44 |
7 |
1.5-3.0 |
1'' |
H07RN-F3G1.0mm2 |
1.2 |
11.5 |
GP011200-1C |
230/50,115/60 |
1200 |
3800 |
48 |
7 |
1.5-3.0 |
1'' |
H07RN-F3G1.0mm2 |
1.2 |
12.0 |
