Tailed and Tested for you!  PSC DC 48v Temperature Based Speed Controller for your Fan   ----PSC Motor and Fan

Company Profile

PSC Motor and Fan is an American company specialized in Thermal Solution since 1993, and its main products are DC/AC/ECAC Backward Curved Impeller, Centrifugal Fan, Axial Fan, Blower and CPU Cooler.

PSC has been a major supplier to HP Compaq, IBM, ATI, Cisco Systems, Rockwell Automation, APC (American Power Conversion, SGI and other many well-known companies in the world.

Key Features

Weight: 92g
Feature: Two fans can be controled at a time
Rated Voltage: 24/48V DC
Operating Voltage: 18V~58V DC
Max Load Current: 5.0A per fan
Fan Start-up Temperature: Adjustable from 0℃ to 29℃
Fan Full-speed Temperature: Adjustable from 30℃ to 45℃Note: Alarm temperature must be setted 3℃ higher than Full-speed temperature at setting logic.
Tachometer Output: Open collector, 4 pulses/Rev
Tachometer Output Current: Max 20mA
Alarm Output: Fan failure alarm and over temperature alarm
Alarm Output Current: Max 20mA
Digital Display Screen: Instant ambient operating temperatureFan operating status and speed
Thermal Sensor Lead Wire Length: 500mm
Life Expectance: 50,000 hours5V high-level alarm output signal will drive relay to turn on
Over Temperature Alarm: Adjustable from 30℃ to 55℃

Base Parameter

Erp 2015

For products with an input capacity between 125 W and 500 kW, the new European Energy-related Products Directive (ErP) to improve energy efficiency will enter into force in 2015 at the latest. Thanks to leading edge PSC EC technology, all PSC fans and motors in these performance classes exceed the ErP Directive even today.

ECAC Technology

When PSC Motor and Fan describes their range of ECAC products, we use the acronym “ECAC,” to refer to an electric motor, fan, blower or impeller that is powered by Electronically Commutated Alternating Current.

This means that the power to the unit comes out of the available power socket; this is 115V AC in the US and 230V AC in Europe and Asia.

Each PSC ECAC Motor is equipped with sophisticated on-board Voltage Conversion Circuitry that converts the 115V AC or 230VAC power input to 90V DC power, and it is this current that actually powers the Motor.

As the motor itself is now actually powered by DC input, we can now incorporate the standard DC Motor functionality that would not be available with a standard AC powered unit.

This functionality includes the following features:

l  The biggest benefit is PWM Speed Control or Analog Speed Control. This allows the User to vary the RPM of the motor to whatever speed is needed by his system; with a standard AC motor, it has to run at maximum speed at all times.

l  A Tachometer Out Signal is provided, so that the User can monitor the performance of the motor. This signal usually provides 3 Pulses per Revolution.

l  An Alarm Signal can also be available which tells the User if the Motor has stopped for some other reason.

The major advantage of ECAC technology, as compared to a straight AC-powered electric motor, is the Power Savings.

As an example, a standard 225mm AC Impeller may consume 160 Watts in power, whereas an equivalent 225mm ECAC Impeller may consume only 108 Watts in power, thereby using 62 per cent as much power as the AC unit.

ECAC powered electric motors, and by extension the full range of ECAC air moving devices manufactured by PSC Motor and Fan, will see on average a drop in power consumption of at least 30 per cent over an equivalent conventional AC powered unit.
