Help Center2014 Latest Technology Fly Ash Brick Making Machine in India Price
Related Products
-
Eco-friendly Block Making Machine 4-25US$ 10,000 - 13,000MOQ: 1 Set -
DY-150T Automatic Cement Brick Moulding Machine Sancialo Block Machine in PakistanUS$ 5,000 - 9,000MOQ: 1 Set
-
DY-150TB Cement Concrete Brick Making Machine, Concrete Brick MakerNegotiableMOQ: 1 Set
-
Hydraulic Manual Paving Block Making Machine DY-150TBNegotiableMOQ: 1 Set
-
DY-150TB Small Machines for Concrete PaversUS$ 7,549 - 8,149MOQ: 1 Set
Specifications
1.Block making machine2.Moulding period: 15-20S
3. Produces hollow, solid, and curbing bricks
4.Siemens or ABB motor
Main features of QT8-15 fly ash brick making machine in india price
1. Designed and manufactured with Germany technology.
2. Multi-functional: it can make various bricks by different moulds
3.Equipped with Siemens motors and Mitsubish PLC
4. ISO9001/CE/SGS
5.Oversea offices
QT8-15 cement brick machines factories
Screw Conveyer (Optional fitment): loading bins of the instrument for transporting Fly Ash from the silos(optional fitting) or cement hopper (optional fitting) to the Batching Plant.
Batching Plant: It consists of three loading bins and one weighing bin. It also contains blet conveyers to convey materials from loading bins to weighing bin. Batching and weighing is done by PLC control. We can load three different types of material into the loading bin.
Conveyer Belt: When the Batching plant’s weighing bin trips according to the PLC control, the material comes to this conveyer belt. Then conveyer belt carried materials to the Mixture Machine.
Concrete Mixture Machine: All the ingredients are mixed in this mixture machine. Mixing time and speed is controlled by PLC. The inbuilt water pump adds water to the mixer automatically, as per requirement.
Block mold machine: This is key of the production line. It can press the mixed material. So it can make various hollow block, solid brick, paver brick and kerbstone.
Stacker: Stacker is used to lay the block automatically, which is high-efficient and labor saving.
What’ the main Parameters?
Dimension machine |
3500×1700×2930mm |
Host machine power |
36KW |
Moulding area |
800×820mm |
Vibration force |
60-80KN |
Moulding period |
15-20S |
Capacity |
93.55KVA |
The size of the pallet |
980×900×25mm |
Mixer model |
JS750 |
Weight of the host machine |
8.5T |
General water Consumption |
9T/every day |
Voltage |
380V/440V |
Theoretical output of hot sale QT8-15
Size(LxWxH) |
Pcs/Mould |
Pcs/ Hr |
Pcs/ 8 Hr |
m3/year |
400X100X200 |
16 |
2880-3360 |
16800-23520 |
23040-26880 |
400X150X200 |
10 |
1800-2100 |
12000-16800 |
14400-16800 |
400X200X200 |
8 |
1440-1680 |
9600-13440 |
11520-13440 |
400X250X200 |
6 |
1080-1260 |
7200-10100 |
8640-10080 |
|
Paver:200X100X60 |
32 |
5760 |
33600 |
46080 |
|
Paver:200X163X60 |
30 |
3600 |
14400 |
28800 |
What advantages do we have?
(1) Fully automatic and hydraulic block making machine. Our products can produce all kinds of bricks by changing moulds, such as the solid bricks, hollow blocks, paver blocks and so on.
(2) German Siemens motors, Japan Mitsubishi PLC system, Omron travel switch are adopted.
(3) We adopt the heat-treatment and carburization technique to increase the lifespan of the moulds.
(4) Certificates: SGS/CE/ISO9001.
(5) Strong Steel Structure made of Q235B.
(6) There are three same size oil cylinders, which work at the same time to insure the same density and high quality of the blocks.
(7) 360° revolving method ensures the material to be more uniform.
(8) Cooling pump is installed to cool the oil so as to insure work of the hydraulic system.
(9) Waste recycling tank is used to reduce the waste of materials.
A:Service process
1.Preliminary investigation:
Local raw material condition, market demand and the potential for long-term
growth are the factors which shall be considered.
2.Whole plant planning:
Engineers’ selection of the equipment configuration and the technological layout are the basis of the optimum
scheme.
3.Speedy delivery:
Excellent processing and manufacturing capabilities and reputable quality assurance system ensure the clients
the fastest investment returns.
4.Installation and debugging:
We have domestic first-class commissioning engineer team and serve 400 clients around the world.
5.Training:
The training starts from equipment installation and debugging and ends to the point where the operator is able to run production on his own; it also aims to help establish the only domestic training base of the model line at the same time.
B: After-sales service:
1.The expert group will conduct a thorough observation and analysis in the trial operation and develop a
preventive maintenance program to ensure high production capacity and cost control.
2 . 24 hours service hotline help customers diagnose and solve the problem of production system.
3. Our service does not stop with the handover of the equipment to the customer but lasts for the lifetime
of the machine.
What guaranty can we supply?
-FOR PRODUCT
Company guaranty is 12monthes.
-FOR BUSINESS
Based on more than 7 years exporting experience, Sancidalo is always fast & effectively. We help our customers on matters other than orders
Clearing Customs, CO/CCPIT to save taxes, shipping arrangement and some other unpredictable knotty problems
With 7 years experience on equipment exportation, Linyi Sancidalo Import & Export Co., Ltd. is able to offer you whole set of solution. But we are very young on Alibaba. As a baby, we focus more on quality, price and service. We treat you not only as business partner, but also as our friend.
