TM-1500SB uv Screen Exposure Machine

TM-1500SB uv Screen Exposure Machine thumbnail-1
TM-1500SB uv Screen Exposure Machine photo-1
US$ 1,199 - 1,329 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
LC, LC,China
Contact Supplier Request Quote Chat Now
Luen Cheong Printing Equipment Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN CHINA
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Guangdong, China
Brand Name LC, LC,China
Model Number TM-1500SB
Usage Other, uv exposure machine
Automatic Grade Semi-Automatic
Voltage AC110V/220V, 220V/50HZ
Gross Power 50W
Dimensions(L*W*H) 1250*1550*900mm
Weight 155kg, 155kg
Certification CE
Warranty life time guarantee
After-sales Service Provided Engineers available to service machinery overseas

Specifications

UV screen exposure machine
1.Used in the filed of plate-making,pad plate.
2.machine size can customized
3.easy operati0on

Product name

uv light exposure machine

Model No

TM-1200SB

Certificate

CE, ISO-9001-2000

Brand Name

LC,China

Description

Used in the filed of plate-making such as pad plate, screen plate, hot stamper plate, resin plate. When you put the film onto the plate into UV exposure machine, start it, the emulsion on the plate will appear a unseen imagine. This is important process on all plate-making technology. Flexibility Rubber Film ensure Film contact compactly with surface of slik when vacuum state


Advantage

1.Vacuum absorbing, the high quality elastic sealed rubber cloth, let the film tightly contact to the screen, and so ensures the clear designs;
2. Suitable for exposure the pad plate.
3. Famous Exposure system brand ensures the stable and even exposure.
4. Instance it comes into the vacuum condition, save much plat-making time.
5. Easy to operate, convenient to adjust the exposure time.
6. Choose high quality UV lamp which keep a long life span.
7. Whole jointing with zinco plate, both portability and firmly.
8. Exposal time auto adjustment and controlling.
9. High vacuum degree, easy to transfer and copy fine lines;
10. Automatic door of UV lamp shut off and turn on when exposure and finsi ensure long life of UV lamp;
11. The upper panel adopts toughened glass, nice rigidity and high tansparence

Parameter

1. Model number: TM-1500SB
2. Glass Table dimension: 1210*1510mm
3. Max. Screen stencil size: 1200*1500mm
4. Voltage: 220V/50HZ
5. Lamp wattage: 2KW
6. Dimensions(W*L*H): 1250*1550*900mm
7. Weight: 155kg

Usage

Used in the filed of plate-making such as pad plate, screen plate, hot stamper plate, resin plate

Free fittings

1. 1 PCS uv LAMP

2. Work box
3. English operating instruction

Shipping way

By sea, by air, by express

Delivery time

Within 5 days from the receipt of payment

Loading seaport

Shenzhen or Hong Kong, China

package

Plywood case

Price term

FOB Shenzhen, CFR, CIF, FCA, EXW etc

Payment term

100% T/T in advance(negotiation)
