LCB-120UV-1 Automatic Single Round Screen Printing Machines

LCB-120UV-1 Automatic Single Round Screen Printing Machines thumbnail-1
LCB-120UV-1 Automatic Single Round Screen Printing Machines photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
LC
Contact Supplier Request Quote Chat Now
Luen Cheong Printing Equipment Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Guangdong, China
Brand Name LC
Model Number LCB-120UV-1
Usage Other, round screen printing mahcines
Automatic Grade Automatic
Voltage AC380V
Gross Power 50W
Dimensions(L*W*H) 1900*1000*1500(mm)
Weight 1000kg
Certification CE
Warranty LIFE TIME GUARANTEE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

round screen printing mahcines
1,1.Full automatically printing suitable to print on various shades of cylindrical, elliptical

Product name

LCB-120UV-1 Automatic Single Round screen printing machines

Model No

LCB-120UV-1

Certificate

CE, ISO-9001-2000

Brand Name

LC,China

Description

Full   LCB-120UV-1 Automatic Single Round screen printing machines

This screen printing machines  is specially used for printing different patterns on the objects with round shape or oval shape. As it is made up of several individual units to form a printing chain, it can be used for the purpose of one-color printing. The materials to be printed can be plastic, glass, ceramics, metal, etc



Advantage

1.Full automatically printing suitable to print on various shades of cylindrical, elliptical and falt workpieces;

 2.Coupled with auto workpiece feeding and loading system;

3.Flame treatment device adopted for re-treatment on PE or PP workpieces to get ultimate ink adhesion;
4.The function of workpiece placing in advance is built-in aiming on cylindrical or elliptical printing;
5.Electric sensor creates "no workpiece no printing" that leads to intelllgent monitor and smart control;
6.High quality UV curing system adopted to ensure fast ink drying and color registration;
7.High printing speed that up to 4000pcs/hr will bring you with high productivity;
8.Conveniently and easily fixture adjustment and change that save your valuable time;
9.Multi-sets of this machine can achieve 2-color, 3-color and even 4-color auto printing system

Parameter

1 Model No:LCB-120UV-1
2.Printing colors:1 color
3.Product appearance:Round bottle /  oblate bottle
4.Operation:Full Auto
5.min printing diameter:round bottle: 20 mm
6.max printing diameter:round bottle :100 mm
7.min printing radius:oblate bottle :25 mm
8.max printing radius:oblate bottle :260 mm
9.oblate bottle width:20-100 mm
10.oblate bottle thickness:20-80 mm
11.Max Printing speed:4000-5000Pcs/Hr
12.Power:380V
13.Weight:1050(kg)
14.Dimensions:L:1900×W:1000×H:1500(mm)

Usage

 As it is made up of several individual units to form a printing chain, it can be used for the purpose of one-color printing. The materials to be printed can be plastic, glass, ceramics, metal, etc .

Free fittings

SILK SCREEN PLATE ,SQUEEGEE,



LCB-120UV-1 Automatic Single Round screen printing machines

LCB-120UV-1 Automatic Single Round screen printing machines

LCB-120UV-1 Automatic Single Round screen printing machines LCB-120UV-1 Automatic Single Round screen printing machines

LCB-120UV-1 Automatic Single Round screen printing machines LCB-120UV-1 Automatic Single Round screen printing machines
