Specifications
Our CCA welding cables sell well in Mid-east, South-east Asia,Africa.. we are sure our price is the best with the same quality.CCA welding cable:
Rated Voltage: 100/100V
Cores:1
conductor: CCA(Copper Clad Aluminum)
insulation:PVC, temperature: -15~70 C
These cables are used for connecting the electrodes to the welding equipment,charger machine. These cables are suitable for welding equipment,charger machine in industry , in automated welding equipment, in tooling constructions, automobile and ship
building as well as for hand-held electrodes in workshops and at building sites.
These flexible and robust current-carrying cables are suitable for use at high mechanical loads in dry indoors.
CCA welding cable struction | |||||
Conductor section:10-185mm2 Rated voltage:100/100V | |||||
Line core number and conductor nominal section |
Norminal thinkness of insulation/sheath(mm) |
Overall Diameter (mm) |
At 20 DC Resistance of conductor (Ω/km) |
||
|
Min mm |
Max mm |
Tinned conductor |
Non-tinned conductor |
||
1x10 |
2.0 |
7.7 |
9.7 |
1.95 |
1.91 |
1x16 |
2.0 |
8.8 |
11.0 |
1.24 |
1.21 |
1x25 |
2.0 |
10.1 |
12.7 |
0.795 |
0.780 |
1x35 |
2.0 |
11.4 |
14.2 |
0.565 |
0.554 |
1x50 |
2.2 |
13.2 |
16.5 |
0.393 |
0.386 |
1x70 |
2.4 |
15.3 |
19.2 |
0.277 |
0.272 |
1x95 |
2.6 |
17.1 |
21.4 |
0.210 |
0.206 |
1x120 |
2.8 |
19.2 |
24.0 |
0.164 |
0.161 |
1x150 |
3.0 |
21.1 |
26.4 |
0.132 |
0.129 |
1x185 |
3.2 |
23.1 |
28.9 |
0.108 |
0.106 |
Update Date:2010-12-17 1:01:28
