Vacuum Lifter for Glass Sheet

Vacuum Lifter for Glass Sheet thumbnail-1
Vacuum Lifter for Glass Sheet thumbnail-2
Vacuum Lifter for Glass Sheet thumbnail-3
Vacuum Lifter for Glass Sheet thumbnail-4
Vacuum Lifter for Glass Sheet thumbnail-5
Vacuum Lifter for Glass Sheet thumbnail-6
Vacuum Lifter for Glass Sheet photo-1
Vacuum Lifter for Glass Sheet photo-2
Vacuum Lifter for Glass Sheet photo-3
Vacuum Lifter for Glass Sheet photo-4
Vacuum Lifter for Glass Sheet photo-5
Vacuum Lifter for Glass Sheet photo-6
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Load
Place of Origin:
Shanghai, China
Contact Supplier Request Quote Chat Now
Shanghai Herolift Automation Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Load
Place of Origin Shanghai, China
Brand Name herolift
Model Number BLS800-8-T
Certification CE

Specifications

1. Vacuum lifter for glass sheet
2. Max. load 600kg
3. Horizontal and vertical handling

Vacuum lifter for glass sheet /lifting and tilting equipment

Detail product Description:

used with crane + hoist+ vacuum lifter

1. The vacuum lifter device max. carrying capacity up to 800kg.

2. For handling steel boards, aluminium boards, plastic boards, glass boards, stone slabs, laminated chipboards

The vacuum lifting equipment consists of the basic unit that can be combined with different suction systems.

The vacuum lifter can be combined and operated with many different carrier facilities,such as crane, wheel loaders, fork lifts. hoist.



Characteristics

  • Max. carrying capacity up to 800kg (a safety factor 4.0 include)
  • Size of pad diameter(mm): 300mm
  • Power supply: 380Volts AC, 50HZ, 3 Phase.(or as client request)
  • Horizontal and Vertical handling
  • Acoustic warning
  • Intergrated safety tank
  • Imported oillness Pump &Valve, vt4.8, 8m³/h
  • Safety Tank &pressure switch warning
  • Noise level, Less than[65dB]
  • High-duty vacuum pump with a low degree of maintenance
  • Optical and acoustical warnning system
  • Fiter system against dust and water
  • High carrying capacity
  • Suction plate control via manual sliding valve/ball valve or optionall via remote control
  • Low set-up time-quick readiness for peration by quick change systems for the suction plates
  • Unevenness is compensated to a high degree by the movable suspension of the sution plate

Load(kg)

Type

size of suction cups (mm)

Turning

vacuum control

vacuum pump

power

V/HZ/PH

W(kg)

Overall of machine (mm)

200

BLS250-4-T

230

none

manual

VT4.4

380^50/60^3

60

1200*800*500

500

BLS500-6-T

300

90degree

manual

VT4.8

380^50/60^3

130

1800*800*500

750

BLS750-8-T

300

90degree

manual

VT4.8

380^50/60^3

140

1800*800*500

1000

BLS1000-10-T

300

90degree

manual

VT4.8

380^50/60^3

180

2500*1200*500

 Vacuum lifter for glass sheetVacuum lifter for glass sheetVacuum lifter for glass sheet
