Single Conductor 600 V Secondary Type UD Cable Aluminum Conductor
US$ 0.1 - 5
MOQ: 1 Kilometer
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
hongda
Model Number:
35MM electrical cable
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
300/500V 450/750V Pvc Insulated Wires Copper Conductor Electric Cable and WiresUS$ 0.15 - 2MOQ: 1 Kilometer -
H07V-R Cable With Copper/Aluminum PVC Insulation Flexible WiresUS$ 0.1 - 3MOQ: 5 Kilometers
-
1*25mm2 Low Smoke Zero Halogen Power Electric Wire ( H07Z-K)US$ 1.7 - 1.77MOQ: 1000 Meters
-
LSOH Power Cable /Power Electric Wire ( H07Z-K) in a 1*95mm2US$ 5.8 - 5.85MOQ: 1000 Meters
-
Low Smoke Zero Halogen Power Electric Wire ( H07Z-K)US$ 0.4 - 0.43MOQ: 1000 Meters
Place of Origin
Henan, China
Brand Name
hongda
Model Number
35MM electrical cable
Type
Insulated
Application
Underground
Conductor Material
Aluminum
Conductor Type
Stranded
Insulation Material
PE
Specifications
Single Conductor 600 V Secondary Type UD Cable Aluminum ConductorAluminum conductor cable
fast delivery
Aluminum conductor cable
Single Conductor 600 V Secondary Type UD Cable Aluminum Conductor
Applications of aluminum conductor cable
Directly buried or installed in ducts for 600 volt secondary distribution.
Construction of aluminum conductor cable
Concentric stranded or compressed 1350-H19 aluminum conductor, crosslinked polyethylene insulation.
Standards of aluminum conductor cable
Secondary UD single conductor 600V cable meets or exceeds the following ASTM specifications.
- B-230 Aluminum Wire, 1350-H19 for Electrical Purposes.
- B-231 Aluminum 1350 conductors, Concentric-Lay-Stranded.
- B-786 "19 Wire combination unilay-stranded Aluminum Conductors for subsequent insulation".
- B-901 "Compressed round stranded Aluminum Conductors using single input wire construction".
- Secondary UD single conductor 600V cable meets or exceeds all applicable requirements of ICEA S-105-692.
- "USE-2" per UL 854 available upon request.
Options - Cable in Duct (CIC)
- Abrasion Resistant
Ampacity
90oC conductor temperature, 20oC ambient, RHO factor 90, 100% load factor for three conductor triplexed, 3 phase operation. To determine correct ampacity by conductor size, please consult the National Electric Code, latest edition.
Specification Size and Technical Data of pvc insulated electrical cable
| Nominal sectional area mm2 |
Conductor No/Dia. mm |
Nominal Insulated thick mm |
Max overall Dia. mm |
Condcutor Resistance at 20 |
Min insulated resistance at 70MΩ/km |
Weight Kg/km |
||
| Cu | Al | Cu | Al | |||||
| 1.5 | 1/1.38 | 0.7 | 3.3 | 12.1 | - | 0.011 | 19.2 | - |
| 1.5 | 7/0.52 | 0.7 | 3.5 | 12.1 | - | 0.010 | 20.6 | - |
| 2.5 | 1/1.78 | 0.8 | 3.9 | 7.41 | 11.8 | 0.010 | 30.8 | 15.0 |
| 4 | 1/2.25 | 0.8 | 4.4 | 4.61 | 7.39 | 0.0085 | 45.5 | 21.0 |
| 6 | 1/2.76 | 0.8 | 4.9 | 3.08 | 4.91 | 0.0070 | 65.0 | 29.0 |
| 10 | 7/1.35 | 1.0 | 7.0 | 1.83 | 3.08 | 0.0065 | 110.0 | 52.0 |
| 16 | 7/1.70 | 1.0 | 8.0 | 1.15 | 1.91 | 0.0050 | 170.0 | 70.0 |
| 25 | 7/2.14 | 1.2 | 10.0 | 0.727 | 1.20 | 0.0050 | 270.0 | 110.0 |
| 35 | 7/2.52 | 1.2 | 11.5 | 0.524 | 0.868 | 0.0040 | 364.0 | 150.0 |
| 50 | 19/1.78 | 1.4 | 13.0 | 0.387 | 0.641 | 0.0045 | 500.0 | 200.0 |
| 70 | 19/2.14 | 1.4 | 15.0 | 0.268 | 0.443 | 0.0035 | 688.0 | 269.0 |
| 95 | 19/2.52 | 1.6 | 17.5 | 0.193 | 0.320 | 0.0035 | 953.0 | 360.0 |
| 120 | 37/2.03 | 1.6 | 19.0 | 0.153 | 0.253 | 0.0032 | 1168.0 | 449.0 |
| 150 | 37/2.25 | 1.8 | 21.0 | 0.124 | 0.206 | 0.0032 | 1466.0 | 551.0 |
| 185 | 37/2.52 | 2.0 | 32.5 | 0.099 | 0.164 | 0.0032 | 1808.0 | 668.0 |
pe insulated electrical cable , secondary cable, Aluminum conductor cable
welcome to inquire us pvc insulated electrical cable, Aluminum conductor cable
