Specifications
electric cable and wire with competitive pricehot sale!!!
ISO certification
prompt delivery
pvc insulated wires
300/500V 450/750V copper conductor, electric cable
pvc insulated wires
Our PVC Insulated electrical wire has passed CCC and ISO qualified,we can supply you the best quality with the best price.
Single Core Wire supplier - hongda electric Cable, offer you with pvc insulated single core wire, insulated cable & wire, power cable,.
Application:The product is appiulicable on the distribution of AC rated voltage below 450/750v with the use for wiring.
Standards:
GB5023-1997 PVC insulation cables voltages up to and including 450/750v
GB734-1998 PVC insulation cable wire and soft line voltages up to and including 450/750v
Conductor: Cu or Al
Insulation: PVC
Table 1-1Type and Description of cable
Type |
Description |
Core |
Area |
voltages |
227IEC01 |
Signal-core hard drawn non-sheathed cable(BV) |
1 |
1.5~400 |
400/750 |
227IEC01 |
Signal-core soft drawn non-sheathed cable(RV) |
1 |
1.5~240 |
400/750 |
227IEC05 |
Signal-core solid conductor drawn non sheathed cable for internal wiring is 70°C(BV) |
1 |
0.5~1.0 |
300/500 |
227IEC06 |
Signal-core soft conductor drawn non sheathed cable for internal wiring is 70°C(RV) |
1 |
0.5~1.0 |
300/500 |
227IEC07 |
Signal-core solid conductor drawn non sheathed cable for internal wiring is 90°C(BV-90) |
1 |
0.5~2.5 |
300/500 |
227IEC08 |
Signal-core soft conductor drawn non sheathed cable for internal wiring is 70°C(RV) |
1 |
0.5~2.5 |
300/500 |
227IEC10 |
Light PVC sheathed cable |
2,5 |
1.5~30 |
300/500 |
227IEC52 |
Light PVC sheathed soft cable |
2,3 |
0.5~0.75 |
300/500 |
227IEC53 |
Ordinary PVC sheathed soft wires |
2,5 |
0.75~2.5 |
300/500 |
BV |
Cu-core PVC insulated wires |
1 |
0.75~1.0 |
300/500 |
BLV |
Al-core PVC insulated wires |
1 |
2.5~400 |
450/750 |
BVR |
Cu-core PVC insulated soft wires |
1 |
2.5~70 |
450/750 |
BVV |
Cu-core PVC insulated and sheathed circle type wires |
1 |
0.75~10 |
300/500 |
NH-BV |
Flame-resistant power cable(wire) with Cu core PVC insulation |
1 |
1.5~300 |
450//750 |
NH-BVV |
Flame-resistant power cable(wire) with Cu core PVC insulation &sheath |
1~5 |
1.5~300 |
450/750 |
NH-RVV |
Flame-resistant power soft cable with Cu core PVC insulation &sheath |
1 |
1.5~300 |
600/1000 |
2~5 |
10-240 |
600/1000 |
