Specifications
UL 1330/1331 FEP Teflon Insulated 600V Wirequality,low price
Pass UL,VDE,CCC
OEM manufacture
UL 1330/1331 FEP Teflon Insulated 600V Wire
1.Rated voltage:300V
2.Temperature range:~100-150°C
3.Conductor:tinned cooper(or for customer's request)
4.Insulation:silicon+Fiber glass
5.O.D.allowance:+/-0.10mm
6.Testing voltge:2500V
lor:White/blue/red/black/brown/yellow/green/yellow with green
| AWG |
Construction No.*dia(mm) |
insulation thickness (mm) |
average overall dia(mm) |
conductor resist- ance at 20°c(Ω/km) |
| 16 | 7*0.50 | 0.39 | 2.58 | 14.6 |
| 17 | 32*0.20 | 0.39 | 2.42 | 18.3 |
| 18 | 7*0.40 | 0.39 | 2.28 | 23.2 |
| 20 | 7*0.32 | 0.39 | 2.04 | 36.7 |
| 22 | 7*0.26 | 0.39 | 1.86 | 59.4 |
| 24 | 7*0.20 | 0.39 | 1.68 | 94.2 |
| 26 | 7*0.16 | 0.39 | 1.56 | 150 |
| 28 | 7*0.12 | 0.39 | 1.14 | 239 |
| 30 | 7*0.10 | 0.39 | 1.08 | 381 |
Used for internal wiring of commercial, industrial,household ovens and lighting fixture.
Ideal for use in electric heaters and for equipment wiring as high temperature lead wire.
Our Advantage
1.We are 100% factory with 7years history.
2.We can make the new products as your own design.
3.Our products are approved by UL, CE,ROHS, CCC, and VDE.
Can supply free sample before you order.If make your type,
Please supply us your detailed spec.
WELCOME TO YOUR INQUIRY !
