Home > Products > Linear scale (linear encoder) > 24V Linear Glass Scale(measuring Length 100mm)
24V Linear Glass Scale(measuring Length 100mm)
- chengdu
- Credit Card
You May Like
Product Details
| Place of Origin | Sichuan, China | Brand Name | DITRON | |
| Model Number | DC10 |
Product Description
DC10 (50mm—1000mm,5um)
DC11 (50mm—1000mm,1um)
DC20 (1100mm—3000mm,5um)
DC21 (1100mm—3000mm,1um)
Some specification:
Measuring range:50mm-3000mm
Grating space:20um,10um
Infrared wave length:88omm
Rolling system: vertical five bearing rolling system
Output signal: TTL,EIA-422-A(RS-422),~1VPP
Resolution:1um,5um,0.5um,0.1um,0.2um
Environment temperature:-10~45°C
humidity:<=90%
working speed:(resolution)>=5um:>=60m/min
<=1um:>=20m/min
Superiority:
1)The reading head adopts ball bearing to position and guide with high sensitivity & long life.
2) Adopting metrology grating as measuring datum with high accuracy.3)Adopting sealed structure that has reliable performance & is convenient for installation.
4)Glass precision measuring grating is adopted for the Linear Encoder as measuring benchmark to ensure high precision
5)Individualized components makes it very easy to install, maintain and repair the linear Encoder
