Help CenterOMR Answer Sheet Reader/ Optical Mark Recognizer OMR S50FBSA Double Sides Scanner/evaluation Scanner
Related Products
-
NANHAO New Portable OMR Scanner (NHII 25FSMA)US$ 500 - 1,000MOQ: 1 Set -
NHII OMR Scanner S43FSA /OMR Scanner for the School Exam / Scoring/barcode Wite Lowest Price MachineUS$ 1,000 - 2,000MOQ: 1 Set
-
S50FSA OMR Solution for the School and OfficeUS$ 1,500 - 2,000MOQ: 1 Set
-
NHII OMR Scanner S50FBSA /OMR Scanner for the School Exam / Scoring/barcode Wite Lowest Price MachineUS$ 1,500 - 2,000MOQ: 1 Set
-
NHII H50FSA OMR Scanner for the School Exam /scoring/testing/ Barcode Machine/lowest PriceUS$ 1,500 - 2,000MOQ: 1 Set
Product Name: Optical Mark Reader S50FBSA
Main application fields:
In important examinations, signing up, statistics, cadres evaluation, voting, especially in population, industry, agriculture, maintenance, diseases and forestry industries, which require heavy reading. Mainly in European countries.
Specifications:
Model: |
OMR50FBSA |
Reading mode: |
double-face and read one times |
Feeding mode: |
automatic |
Speed: |
7500pcs/hour (based on A4) |
Form size: |
130mm×50mm-300mm×210mm |
Form weight: |
70-150g/m2 |
Track spacing: |
4.23mm |
Marking tools: |
No.2 or softer pencils,carbon pens |
Mark shapes: |
Rectangles,ovals and circles |
Error rate: |
≤1×10-7 |
Mark choice: |
single choice, multiple choice and BCD code |
Format: |
26 kinds, each has 255 commands at most |
Interface: |
RS232 serial,USB |
Host: |
PC, Laptop |
Weight: |
8kg |
Operating system: |
Win2000, Win2003, Win XP, Win7 |
Power supply: |
AC90-264V, 50-60Hz |
Dimensions: |
560mm×170mm×400mm |
Operating condition: |
temperature 0-40°C, humidity≤90%, no erosive gas |
OPTIONS:
- Barcode reader: Code39 ,Interleaved 2 of 5 Code, Character Set C of Code128
- Ink reader: Blue and black ballpoint pens, markers and pencils
- Classroom testing
- Customer satisfaction surveys
- Course evaluations
- Climate surveys
- Instructor evaluations
- Conference evaluations
- Skills testing
- Quality inspections
- Training and development surveys
NANHAO GROUP
NANHAO group is the biggest OMR manufacturer in China, engaged in R&D, manufacturer, sales and servives of education information products in China for 20 years. With reliable quality and competitive price, NHII OMR sales well in over 40 countries such as USA, Turkey, Russia. All products comform to ISO9001,CE, FCC, C-TICK, ROHS.
As the earliest and biggest OMR manufacturer in China, our NHII Optical Mark Reader (OMR Scanner) series have occupied nearly over 86% of China's market and 56% of the world market. With excellent performance and competitive price, NANHAO OMR Series products have been exported to America,Turkey, Vietnam, Mexico, Poland, Korea, Spain, Russia, Thailand, Pakistan and so on. It’s applied for the examinations of the Ministry of Education in Vietnam for three years and imported by Indian Exam Committee, and are very popular in Turkish large exams.
International cooperation
Our scanner can well read various formats of answer sheet. We have profestional factory to design and print answer sheets for you you. What's more, find local factory to design and print the sheets are also acceptable, only if it conform to OMR sheets' requirements.
What isOMR
Optical Mark Reader(OMR scanner) is a high-tech data input device integrated optical and electrical technology.
OMR solves entirely the bottleneck problem of data input. It is a powerful tool for speedy automatic data capture. The speed is several hundreds of times faster than that of manpower, especially the machine can work for a long time without break, which is the fastest data collection technology so far. NANHAO OMR can be widely used in education examinations, signing up, subject choice, data statistics and evaluation in fields such as vote, transportation, human resources, fiscal taxation and finance and so on.
If you have any question, pls feel free to contact me
---
Ms. Vivian Ren
Overseas Manager
NANHAO GROUP
Address: No. 458, Changming South Street, Hengshui City, Hebei Province, China
Website:
Tel: 0086-318-2335086
Fax: 0086-318-2335002
Skype: vivian_129
