Telephone Lan Cable China Manufacturer / 28 AWG Cat 5e Cable

US$ 0.12 - 0.2 MOQ: 1000 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

YWD

Model Number:

Cat5e & Cat6 Lan Cable UTP/FTP/SFTP

Shenzhen Yiwanda Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name YWD

Model Number Cat5e & Cat6 Lan Cable UTP/FTP/SFTP

Type Cat 5e

Specifications

1.Unshielded twisted pairs
2.factory direct
3.Computer networks
4.100Ohms 28 AWG 4 pair
5.UL CE Rohs complaint

Detail Specifications:

Cat.5e UTP Patch Cable,with RJ45 8P8C Connector

Rated Temperature:75Degree

Standard:UL444,TIA/EIA568B.2,YD/T1019-2001

Conductor:Stranded bare copper

AWG:28

Insulation:HDPE

Shield:Pe-Tape + Al foil + Pe-Tape

Twisted pair:Four

Drain wire:Solid Tinned copper

Jacket:PVC

Electrical Characteristic:

1.0-100.0MHz Impedance (ohms):100 +/- 15

1.0-350.0MHz Delay Skew (ns/100m):<=45

Pair-to-Ground Capacitance Unbalance (pF/100m):<=330

Max. Conductor DC Resistance 20 degree(ohms/km):93.8

Resistance Unbalance (%):<=5

LAN Cable:

UTP unshielded twisted four pairs category five cables (stranded & solid)
FTP shielded twisted four pairs category five cables (stranded $ solid)
SFTP shielded twisted four pairs category five cables (stranded& solid)
UTP unshielded twisted four pairs enhanced category five cables (stranded& solid)
FTP shielded twisted four pairs enhanced category five cables (stranded &solid)
SFTP shielded twisted four pairs enhanced category five cables (stranded& solid)
UTP unshielded twisted four pair category six cables (stranded & solid )
FTP shielded twisted four pairs category six cables (stranded& solid)
Structure: bare copper, PE insulation, FR PVC/LSOH PVC jacket
Standards: ISO/IEC 11801, ANSI/TIA/ELA-568A
Used as work-station option to the FD/IDF and others
Horizontal cabling, supports TP-PMD audio and integrated
