Rated Voltage 0.6/1kV and Below Power Cables With Extruded Insulation
Usage:
This product applies to power distribution lines or industrial fixed installations with power frequency rated voltage in 1kV or below
Using Attributes:
1 Rated Voltage 1kV
2 The highest temperature of cable conductor: PVC insulation 70℃,crosslinked polyethylene insulation 90℃
3 In short circuit (the longest duration is no more than 5S),
Cable conductor |
Cross Section( mm2 ) |
The Highest Temperature(℃) |
PVC insulation Conductor |
≤ 300mm2 |
≤160 |
>300mm2 |
≤140 |
|
crosslinked polyethylene insulation conductor |
250℃ |
≤250 |
4 laying temperature of cable
As to PVC insulation or sheathed cable,ambient temperature under installation should not be below 0℃
5 The minimum bending radius of cable when installed
Cable |
Unarmored |
Armored |
Memo |
Single-core |
R=20D |
R=15D |
R:minimum bending radius D:cable diameter |
Multi-core |
R=15D |
R=12D |
6 model
copper conductor |
aluminum core |
product item |
VV |
VLV |
PVC insulated PVC sheathed power cable |
VY |
VLY |
PVC insulated PE sheathed power cable |
VV22 |
VLV22 |
PVC insulated steel tape armored PVC sheathed power cable |
VV23 |
VLV23 |
PVC insulated steel tape armored PE sheathed power cable |
VV32 |
VLV32 |
PVC insulated fine steel wire armored PVC sheathed power cable |
VV33 |
VLV33 |
PVC insulated fine steel wire armored PE sheathed power cable |
YJV |
YJLV |
Cross-linked PE insulated PVC sheathed power cable |
YJV |
YJLY |
Cross-linked PE insulated PE sheathed power cable |
YJV22 |
YJLV22 |
Cross-linked PE insulated steel tape armored PVC sheathed power cable |
YJV23 |
YJLV23 |
Cross-linked PE insulated steel tape armored PE sheathed power cable |
YJV32 |
YJLV32 |
Cross-linked PE fine steel wire armored PVC sheathed power cable |
YJV33 |
YJLV33 |
Cross-linked PE fine steel wire armored PE sheathed power cable |
7 Production range
Model |
Number of Cores |
Rated Voltage(0.6/1kV) |
|
Nominal Cross-section(mm2) | |||
Copper conductor(flame retardant,fire-resistant) |
Aluminum Core(flame retardant,fire-resistant) |
1,2,3,4,5 4+1,3+2,3+1 |
2.5-800 |
VV,VV22,VV23,VV32,VV33,YJV,YJV22,VY,YJY,YJV23,JJV33,JJV32 |
VV,VV22,VV23,VV32,VV33,YJV,YJV22,VY,YJY,YJV23,JJV33,JJV32 |
||
contact me for more details.
