Kasda Dual Ethernet Switch SIP Phone With Headset Interface

Kasda Dual Ethernet Switch SIP Phone With Headset Interface thumbnail-1
Kasda Dual Ethernet Switch SIP Phone With Headset Interface photo-1
Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Kasda
Model Number:
KT103
Contact Supplier Request Quote Chat Now
Kasda Networks Inc. (Shenzhen)
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Kasda
Model Number KT103
Type VoIP Phone

Specifications

1. dual Ethernet switch SIP phone with Headset Interface
2. Support 2 SIP accounts
3. G.722 codec support



Product Description

Kasda dual Ethernet switch  SIP phone with Headset Interface

Kasda dual Ethernet switch SIP phone with Headset Interface





Product Specification



Phone features



•Vxworks OS



• Support SIP2.0 (RFC3261) and correlative RFCs



• SIP support 2 SIP servers, and backup SIP proxy servers



• Supports SIP UDP / TCP/ TLS



• SIP support SIP domain, SIP authentication (none, basic, MD5) , DNS name of server, Peer to Peer / IP Call







Display



• Display Resolution: 128x48







Key Features



• Large dot matrix LCD display and soft keys make user



easier to use



• Soft keys programmable



•Supports RJ-9 headset



• Multi languages displayed







Audio Features



•HD voice: HD handset



•Codec: G.711A/u, G.7231 high/low, G.729AB, G.722, G.726-32



•DTMF: In-band, RFC 2833 and SIP INFO



•Full duplex hands- free speaker phone with acoustic



echo cancellation



•Voice Activity Detection (VAD)



•Comfort Noise Generation (CNG)



•Background noise suppression



•Adaptive jitter buffers



•Packet loss concealment



• SRTP



• mute







Advanced Features



•Call forwarding (busy/ no answer/ always)



•Call transfer ( unattended/ attended/ semi-attended )



•Call holding



•Call waiting



•3 way call conference



•Capable of 10 way conversation



•BLF list



•Join call



•Call pickup



•Call park



•Redial



•Call back



•Call completion



•Hot desking



•Auto redial



•Predial



•SIP messaging , MWI



•Flexible dial plan



•Barring function for outgoing calls



•Do not disturb



•Auto answer



•Caller ID display



•CLIR(rejects anonymous calls)



•CLIP(to make an anonymous call)



•Dial without registration



•Call logs with missed calls/ incoming calls/



outgoing calls. Each support 300 records



•Phonebook 500 records



•Speed Dial (abbreviated dialing)



•Hotline/Warm-line



•Call rejection



•Black List/ White List



• Intercom/Intercom barge



•Password dial, DTMF hidden



•Action URL/ active URI



•Voice codec setting for each SIP line



•Multicast



•LDAP, XML phonebook



•Web dial



• Keypad lock, Emergency call







Network/ Security Features



•WAN / LAN:10/100M Ethernet ports



•Bridge mode and route



•PPPoE for xDSL



•802.3af POE(optional)



•VLAN(Voice VLAN/Data VLAN)



•802.1X



•NAT (NAPT)



•NAT transverse :Support STUN client



•DHCP client on WAN/ DHCP server on LAN



•Main DNS and secondary DNS server



•DNS Relay



•SNTP Client



•Firewall and DMZ



•Web management access restricted



•VPN(L2TP/Open VPN)



•ping, Trace route, telnet







Maintenance & Management



•WEB ,telnet and LCD menu management



•Management with different account right



•Recover firmware and factory reset through POST mode



•Upgrade firmware via HTTP, HTTPS, FTP, TFTP



•DHCP option66 and custom option for auto provisioning



•Auto Provisioning to upgrade configuration file



with AES(256) encryption



•TR-069 and Syslog







Physical features



•Adapter Input: AC 100-240V



•Adapter Output: DC 5V/1A



•WAN Port -10/100 BASE-T RJ-45 for LAN



•LAN Port-10/100 BASE-T RJ-45 for PC



•Headset : RJ9



•Power consumption: IDLE: 2.5W Active: 2.8W



•Display Resolution: 128x48 pixels



•Operation Temperature: 0 to 40℃



•Relative Humidity: 10 to 65%



•Main Chipset : Broadcom



• SDRAM: 16MB



• FLASH: 4MB



•Weight- Phone:0.84kg

• Dimension:250x205x60 mm
