Specifications
1. Broadband Business Wide IP Phone2. 2 fast ethernet port
3. Easy installation
Kasda Broadband Business Wide IP Phone
KT101 is an unadorned enterprise IP Phone for the users who have lots of phone calls every day. It is really powerful but affordable.
With easy installation and management, any SMBs or enterprises can deploy them quickly. They are stable for working and reliable for choosing.
Features
l Support SIP 2.0 (RFC3261) and correlative RFCs
l Codec:G.711 A/U Law, G.723.1, G.729a/b, G.722,G.722.1, G.726
l Echo cancellation: Support G.168, and Hands-free can support 96ms, Hand free Speaker Phone
l Support Voice Gain Setting, VAD, CNG
l Full duplex hands-free speakerphone
l NAT transverse: support STUN client
l SIP support SIP domain, SIP authentication (none, basic, MD5), DNS name of server, Peer to Peer/ IP call
l SIP support 2 SIP lines. Can connect to SIP1 and SIP2 server at the same time
l DTMF: Support SIP info, DTMF Relay, RFC2833
l SIP application: support Call forward/ transfer/ holding/ waiting / 3 way talking
l Call control features: Flexible dial map, Hotline, Empty calling reject, Black list for reject authenticated call, limit call, No disturb, Caller ID
l Support Phonebook 500 records
l Incoming calls / Outgoing calls / Missing calls. Each support 100 records
l Support conference and voice record on SIP server
l Support 10 kind of ring type and 1 user ring
l Support IAX2,MWI, SMS
l Support Speed Dial and Memo
l Multilanguage realizes localization
Network Features
l WAN/LAN: Support Route and Bridge model
l Support basic NAT and NAPT
l Support PPPoE for xDSL
l Support DHCP Client on WAN
l Support DHCP Server on LAN
l Support VLAN (optional: voice vlan/data vlan)
l QoS with DiffServ; DMZ; VPN (L2TP)
l Support main DNS and secondary DNS server; DNS Relay, SNTP Client, Firewall
l Network tools in telnet server: Including ping, trace route, telnet client
Maintenance and Management
l Web ,telnet and keypad management
l Management with different account right
l Upgrade firmware through POST mode
l Upgrade firmware through HTTP, FTP or TFTP.
l Safe mode provide reliability
l Support Auto Provisioning (upgrade firmware or config file); Syslog
Specification
Item |
KT101 |
|
|
Adapter (Input/Output) |
Input:100-240VAC 50~60Hz Output:5V/1A |
|
Port |
WAN |
10/100Base-T RJ-45 for LAN |
LAN |
10/100Base-T RJ-45 for PC |
|
Power Consumption |
Idle:1.5W/Active:1.8W |
|
LCD Size |
75 x 28mm |
|
Operation Temperature |
0~40℃ |
|
Relative Humidity |
10~65% |
|
Main Chipset |
Broadcom |
|
SDRAM |
128Mbits |
|
Flash |
32Mbits |
|
|
Dimension (W×H×D) |
220×198×75mm |
|
Weight |
0.94kg |
|
Certification
FCC,CE,CCC,ROHS
