gold finger plating pcb

Specifications

a. gold finger plating pcb
b. PCB Clone&Design
c. Gerber needed
d. Turnkey service
e. UL,SGS,RoHs,TS

gold finger plating pcb



Welcome to Dalian JY Electronic Technology Co., Ltd



What can we supply ?



OEM & ODM  Turnkey service ,High Satification !



1 ) One layer pcb,double sided pcb, Multilayer pcb

2) OEM pcb ,pcb assembly ( gerber ),pcb copy ( samples &pics ),pcb design ( need schematics or ideals )

3) FR4 ,Aluminum PCB, Flexiable PCB,MCPCB ,CEM3













We independently research and develop Internet control system, Internet numericalcontrol system, robot control system and produce hardware and software independently for control management etc.. Also supply clients SAS Marketing Automation. Door bell, car alarm, mobile solar charger design by us is most welcome products.



PCB Certificates Details





All our certificates are just for PCB, not for PCBA, pls notice.



JY Factory Real Photos



The last three pieces photos are pcba factory.





JY Main Clients









JY PCB Engineering Capacity



No.	Item	Spec
1	Layers	1 to 24 layers
2	Max working panel area	457 x 610 mm
3	Min board thickness	4 layer: 0.40mm
		6 layer: 0.80mm
		8 layer: 1.00mm
		10 layer: 1.20mm
4	Min trace width	0.10mm
5	Min spacing	0.10mm
6	Min hole diameter	0.20mm
7	Min Copper thickness in hole	0.020mm
8	PTH size tolerance	±0.05mm
9	NPTH size tolerance	±0.025mm
10	Hole position tolerance	±0.05mm
11	Dimension tolerance	±0.1mm
12	Min solder mask dam	0.08mm
13	Insulation resistance	1E+12Ω (normal condition)
14	Max Board thickness/Hole size Rate	'10:01:00 AM
15	Thermal shock endurance	288 3 times in 10sec
16	Max Board twist and wrap	≤0.7%
17	High Vlotage endurance	1.3KV/mm
18	Copper foil peel off endurance	1.4N/mm
19	Hardness of resist ink	≥6H
20	Flame resistance	94V-0
21	Impedance control	±5%
22	Certificate	ISO 9001:2000;ISO 14001;ISO/TS16949:2002 ,UL E203640



JY PCB QC System





JY PCB Payment way and Delivery way.



Our payment way is  flexible and multiple. For samll quantity order, we supply Express delivery.For mass order,we delivery by ship.



FAQ:



A.For PCB order, please provide Gerber file or *.pcb file. Any details are also welcomed if no Gerber file.



B.Large PCB quantity order, quotation will be based on SQM.



C.For PCBA order, please provide the Gerber file, *.pcb file and BOM List.



D.Reverse engineering and PCB clone service can be supplied with your printed circuit board supplied.



E.Any questions, welcome to contact our sales person Maggie by sending inquiry. Your satisfaction is our pleasure.

...
