| pre-heated copper coil solar water heater . |
CHARACTERISTICS
Key Specification:
Instant heat exchange; plentiful warm water for use
Fresh water quality
Works with pressure
Output water temperature is stable, so it is very comfortable and safe to use
Hot and cold water flow is separated
Copper coil is tested and does not break; high grade materials are used
MATERIAL
1) Inner tank: stainless steel SUS304--0.50mm
2) Vacuum tube: QB-AL-SS/CU-58-1800
3) Outer tank: galvanized steel
4) Frame: coated galvanized steel-1.5mm
5) The material of insulation: polyurethane
6) The reflector: aluminum
7) Copper coil: Φ12mm, thickness 1.0mm
PARAMETER TABLE-1
|
Type (One) |
Area(m2) | Vacuum tube |
Energy exchange area(m2) |
Volume (liters) |
Gross wet(kg) |
Volume/set (Cubic meter) |
||
| Length(mm) | Dia(mm) | Qty(pcs) | ||||||
| JDL-CC20-58/1.9 | 2.8 | 1900 | 58 | 20 | 1.041 | 172 | 120 | 0.75 |
| JDL-CC24-59/1.9 | 3.3 | 1900 | 58 | 24 | 1.106 | 206 | 138 | 0.9 |
| JDL-CC30-58/1.9 | 4.1 | 1900 | 58 | 30 | 1.171 | 260 | 164 | 1.15 |
REMARK
*Solar heat storage tank diameter(mm):360/480
*Thickness,insulated(mm):50
*Max.Fluid pressure(Pa):1MPa
*Operation fluid pressure(Pa):0.4MPa
*Coil connection(inch):1/2
*Hot-outlet(inch):1/2
*Cold-inlet(inch):1/2
*Small tank connection(inch):1/2
*Electric heater connection(inch):1.25
