Home > Industrial Equipment & Components > Power & Generating Sets > Wind Generator > Low Rpm 1000W Wind Turbine Alternator 48v for Off-grid&on-grid System Made in China

Low Rpm 1000W Wind Turbine Alternator 48v for Off-grid&on-grid System Made in China

Low Rpm 1000W Wind Turbine Alternator 48v for Off-grid&on-grid System Made in China photo-1
Low Rpm 1000W Wind Turbine Alternator 48v for Off-grid&on-grid System Made in China photo-2
Low Rpm 1000W Wind Turbine Alternator 48v for Off-grid&on-grid System Made in China photo-3
Low Rpm 1000W Wind Turbine Alternator 48v for Off-grid&on-grid System Made in China photo-4
Low Rpm 1000W Wind Turbine Alternator 48v for Off-grid&on-grid System Made in China photo-5
Low Rpm 1000W Wind Turbine Alternator 48v for Off-grid&on-grid System Made in China photo-6
US$ 480 - 650 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Naier
Model Number:
NE-1000L
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Jiangsu, China
Brand Name Naier
Model Number NE-1000L
Type Wind Power Generator



 low rpm 1000W wind turbine alternator 48v for off-grid&on-grid system made in china







low rpm 1000W wind turbine alternator 48v for off-grid&on-grid system made in china





1000w wind turbine parameters

Model

NE-1000L

Rated power

1000W

Maximum power

1200W

Rated voltage

48/96V

Start-up wind speed

3m/s

Rated wind speed

10m/s

Survival wind speed

45m/s

Top net weight

46kg

Wheel diameter

2.8m

Number of blades

3

Blades material

Reinforced glass fiber

Generator type

Three phase permanent magnet AC synchronous generator

Magnet material

NdFeB

Generator case

Casting aluminum alloy

Control system

Electromagnet/wind wheel yaw

Speed regulation

Tail furling

Working temperature

-40°C  -  80°C

Design life

20 y

Certificates

CE, ISO14001, ISO9001, TUV







1000w wind turbine features

1.Carbon steel body, compact, safe.

2.Reinforced glass fiber blades,matched with optimized aerodynamic shape and structure.

3.Patented permanent magnet ac generator with special stator,effectively reduce torque.

4.Tail adopts mechanical yaw technique, making it survive storm and run safely.

5.With epoxy zinc rich primer and polyurethane anti-corrosion treatment.





1000w wind turbine projects

low rpm 1000W wind turbine alternator 48v for off-grid&on-grid system made in china





1000w wind turbine system diagram

low rpm 1000W wind turbine alternator 48v for off-grid&on-grid system made in china





1000w wind turbine packing

low rpm 1000W wind turbine alternator 48v for off-grid&on-grid system made in china





Certificates

low rpm 1000W wind turbine alternator 48v for off-grid&on-grid system made in china







Customers visiting show





Exhibition show







FAQ



1.  Q:  Does installation Easy ?

      A:    Very easy, every customer can do it by themselves, we will supply all the components for installation and

very details installation manual.



2.  Q:  Does our wind is enough for a wind generator ?

  A: As our wind generator can start running at low wind speed2.5m/s. so your average annual wind speed is more

than 5m/s then you can use it .



3.  Q:  Which model wind generator is suitable for me?

     A: Please contact our sales with following points :

        1. What appliance do you want to running by the system?  How many watts are they and their working time .

        2. Your annual wind speed .

        3. What kinds of system do you want ? On-grid or off-grid



4.  Q:  Can I only buy parts not whole system?

    A: Yes,for example you can manufacture tower in local , we can supply you tower drawing .



Any other questions ,please feel free to contact us .
