Home > Products > Accessory(controller,inverter) > 2kw wind power inverter 96v 120v dc pure sine wave
2kw wind power inverter 96v 120v dc pure sine wave
- 1000 Piece / Pieces per Month
- ShangHai
- T/T Credit Card PayPal
You May Like
Product Details
Place of Origin | Jiangsu, China | Brand Name | naier | |
Model Number | WI20-96-3N01 | Type | Other, inverter |
Product Description
1. Performance Description
² Reliability:Intelligentized, modularized, simple structure design with powerful function and stable performance; the high-quality components and the strict production process make the inverter suitable for severe environment. It also has reliable performance and long lifespan.
² Pure Sine Wave Output: Compared with square wave and modified sine wave, the inverter has stronger load capacity. The apparatus can drive inductive load and any other AC load within the required power.
² LCD Display: The LCD display battery voltage, AC output voltage and status parameters. (Remark: If inverter output capacity ≤2kVA, AC output voltage will not display )
² High Efficiency Transformer Isolation: Power frequency toroidal transformer, which ensures high efficiency and low no-load loss of the inverter.
² Perfect Protection Function: Battery over voltage, over discharge, anti-reverse protection; output over load, short circuit, over temperature protection; lightning protection etc.
² Optional by-pass function: When the battery is over discharge, the inverter will intelligently switch to Utility grid to drive load.
² Optional light control and time control function: According to illumination intensity, the inverter can control output without manual operation. This function is available with our matched controller.
2. Installation Flow
2kw wind power inverter 96v 120v dc pure sine wave
Product Model | WI20-96-3N01 |
Rated Output Capacity | 2kVA |
Rated Battery Voltage | 96VDC |
Over Voltage Shutoff | 136VDC |
Over Voltage Recovery | 132VDC |
Under Voltage Shutoff | 86.4VDC |
Under Voltage Recovery | 96VDC |
No-load Loss | ≤0.2A |
Output Wave | Pure sine Wave |
Display Mode | LCD |
Cooling | Fan |
Rated Output Voltage | 220VAC |
Wave Distortion | ≤4% |
Output Frequency | 50±0.5Hz |
Dynamic Response | 5% |
Power Factor | ≥0.8 |
Over-load Capacity | 120% 1min,150% 10s |
Invert Efficiency | 90% Max |
Isolating Mode | Toroidal Transformer |
Noise (1m) | ≤40dB |
Insulating Strength | 1500VAC,1min |
Protection Functions | Input over voltage protection, Battery under voltage protection, Battery anti-reverse connection protection, Output overload protection, Output short circuit protection, Over temperature protection. |
Ambient Temperature | -20~+55℃ |
Working Altitude | ≤4000m |
Ambient Humidity | 0~90%,Without Condensation |
Dimensions (Lx W x H) | 400×243×352mm |
Net Weight | 20kg |
In order to serve our customers better, our company can adjust parameter configuration according to customer’s requirement. |
Picture of 2kw wind power inverter 96v 120v dc pure sine wave
Appendix I Copper Wire Over Current Capacity
Wire Diameter(mm2) | Over current Capacity (A) | Wire Diameter(mm2) | Over current Capacity (A) |
4 | ≤20 | 16 | ≤90 |
6 | ≤30 | 25 | ≤125 |
10 | ≤50 |
|
3. Introduction
Off-grid pure sine wave inverter is intelligent equipment which can transform the direct current to stable alternating current. The apparatus is used to supply for Traffic inconvenience, the harsh environment of the mountain area, a pasturing area, border, islands and other areas without electricity.
The apparatus has decent appearance, easy operation, and visual indication of LCD, with the perfect protection function, high charging efficiency, and low no-load loss.
