High Gloss uv Coating Machine
US$ 1,000 - 2,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Other
Place of Origin:
Guangdong, China
Brand Name:
TAISAN
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Other
Place of Origin
Guangdong, China
Brand Name
TAISAN
Model Number
600#,1000#,1300#
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Condition
New
Specifications
Curtain coater is applicable for top coating. It can achieve mirror effect and there will be no peeling or pulling grains1. Curtain coater machine is mainly applicable for top coating. It can achieve mirror effect and there will be no peeling or pulling grains etc;
2. It adopts imported original cutting molds. The adjustment of coating thickness is very precise;
3. This equipment is equipped with recycling device that it can recycle and reduce waste;
4. The conveyor belts are made of high quality polyesters, which are resistant to acid and alkali and easy to clean;
5. The speed of conveying device is controlled by AC motor frequency conversion that it can implement stepless frequency speed control;
6. This machine is suitable for all kinds of paints.
| Model | TS-600# | TS-1000# | TS-1300# |
| Working width | 600MM | 1000MM | 1300MM |
| Working height | 2-80MM | 2-80MM | 2-80MM |
| Feeding speed | 10-100M/MIN | 10-100M/MIN | 10-100M/MIN |
| Feeding power | 1.5KW | 1.5KW | 2.2KW |
| Galvanothermy power | 3KW | 5KW | 5KW |
| Pump power | 0.75KW | 0.75KW | 0.75KW |
| Paint type | UV/PU/NC/PE | UV/PU/NC/PE | UV/PU/NC/PE |
| Paint dosage | 40-180G/M2 | 40-180G/M2 | 40-180G/M2 |
| Paint container capacity | 240L | 240L | 240L |
| Electric supply | 380V50HZ | 380V50HZ | 380V50HZ |
| Machine dimension | 3000*1750*1300 | 3000*2050*1300 | 3000*2450*1300 |
| Machine weight | 1.1T | 1.3T | 1.5T |
