high gloss uv coating machine
- 30 Set / Sets per Month
- FoShan China
-
Leizhan Disc sludge thickener for paper pulp making production line
-
2013HOT SELL Stainless steel structure Disc thickener for paper pulp making production line
-
Disc pulp filter machine of fluting and kraft paper production line
-
Leizhan waste paper recycle equipment ZNP series disc thickener/paper processing equipment/paper pulp machinery
-
disc thickener/paper pulp industrial use
-
disc thickener used for washing and thickening/paper making industry
Product Details
Place of Origin: | Guangdong, China | Brand Name: | TAISAN | Model Number: | 760#,1100#,1420# |
Certification: | CE | Warranty: | one year | After-sales Service Provided: | Engineers available to service machinery overseas |
Condition: | New |
Product Description
Specifications
the machine is mainly applicalbled for primer roller coating of panel-type furniture,flat doors,handiwork and blinds,ect.1,The machine is mainly applicable for the primer roller coating of panel-type furniture,flat doors,handiwork and blinds ect.
2,This machine takes the place of traditional coating.It can save time and money.It is highly efficient and protects the environment.It can comparatively save the painting amount by 48'8%.
3,This machine adopts AC motor frequency speed control.
4,The coating rollers are easy to remove and accurate to positon.The height is precisely controlled by count table.
5,The painting roller are made by Japanese imported materials,which are solvent resistant and have a good coating effects.
6,Imported paint extracting air pump is installed that the paint can be dirculated through paint groove.There will be almost no waste.
Model | TS-760# | TS-1100# | TS-1420# |
Working width | 650MM | 1000MM | 1320MM |
Working height | 2-80MM | 2-80MM | 2-80MM |
Feeding speed | 0-30M/MIN | 0-30M/MIN | 0-30M/MIN |
Feeding power | 1HP | 2HP | 3HP |
Paint type | UV/PU/NC/PE | UV/PU/NC/PE | UV/PU/NC/PE |
Paint thickness | 0.002-0.35MM | 0.002-0.35MM | 0.002-0.35MM |
Paint container capacity | 20L | 20L | 20L |
Air pressure | 0.6MPa | 0.6MPa | 0.6MPa |
Air supply | 400L/MIN | 400L/MIN | 400L/MIN |
Power supply | 220V/380V50HZ | 220V/380V50HZ | 220V/380V50HZ |
Machine dimension | 2100*1600*1100 | 2100*1750*1100 | 2100*2300*1100 |
Machine weight | 0.7T | 0.9T | 1.3T |
Contact Us
- Foshan Taishang Machinery Co., Ltd.
- Contact nameHua Yang
- Phone86-757-87263301
- AddressLeping Industry Area,Sanshui District Foshan,Guangdong
-
