I. Introduction of fish food production line
Generally speaking, the products consists of meat, cereal, grain, vitamins, minerals and meat by products with soybean meal, corn meal and cracked meal used to improve the consistency of the products.
II. Features of fish food production line
1. The automatic twin screw fish food production line is mainly used for producing pellet feed of all kinds of animals including fish, pets, livestock and poultry, etc.
2. Advanced and harmonious man-machine environment, the cutting structure of the fish food production line has such outstanding features as novel design, unique and simple structure, easy to install, to unload and easy to operate, etc.
3. Main components use special alloy materials with heat-treat and the service life is longer than domestic similar machine 3-4 times while the costs of production is very low.
4. Screw discharge nozzle use modular design, easy to adjust and low price. We can adjust the cutter to get the different diameter and the length.
5. This kind of fish food production line can make all kinds of fish feed, the pellets can float on water for over 24 hours.
6. The capacity of our automatic fish food production line varies. You can choose any kinds of machine according to your own demand.
7. The electric heating device improves the feed expansion rate, puffing rely on the high temperature which produced by the machine Self-friction and the electric heating, it will reduce much cost.
8. The automatic machine owning to the reasonable design, special materials, the stability, repairs can be guaranteed and ensured.
III. Technical Parameter
Parameters/Model Number |
DXY 65-III |
DXY 70-III |
DXY 85-III |
Voltage |
380V/50HZ |
380V/50HZ |
380V/50HZ |
Total Installed Capacity |
45KW |
55KW |
90KW |
Power Consumption |
35KW |
45KW |
60KW |
Output |
120-150kg/h |
15o-200kg/h |
400-600kg/h |
Dimension (L x W x H) |
2.5x0.8x1.8m |
3.5x0.8x1.8/h |
4.5x1x1.8m |
IV. Flow Chart
Mixing---Extrusion----Drying ----Flavoring --Packaging
V. Device configuration of our fish food production line
Mixer, screw conveyer, screw extruder, air conveyer, multilayer oven, automatic flavoring system, cooling system
VI. Voltage
China: Three phases: 380V/50Hz, Single phase: 220V/50Hz (Adjustable according to different requirements)
Abroad: adjustable
VII. Samples of fish food production line
VIII. Our related extrusion machine/ processing line:
a. Series of Single Screw Extruder/Processing Line
b. Series of Twin-screw Extruder/Processing Line
c. Core Filling Extrusion Snack Processing Line
d. Cereal breakfast corn Flakes Processing Line
e. Nutritional Powder Processing Line
f. Screw, Shell Food Processing Line
g. Protein Food Processing Line
h. Fish Feed Pellet Making Machine
i. Pet Food Processing Line
j. Chewing Jam Center Pet Food Processing Line
k. Automatic Instant Noodle Processing Line
l. Mini Instant Noodle Processing Line
m. Series of Roasting Oven
VIIII. After Sale Service:
a. We can provide factory layout according to customer’s factory size in advance.
b. When we received your deposit of this order, we will ask our engineers to prepare to apply the visa, when the equipment arrived your country, and we will send two engineers to go and help you to install the line, teach your worker(3-4 workers) how to operate the line, until your worker know the line well. c. Our engineers has responsibility to teach your worker how to clean the extruder, how to change the screw, how to change barrel etc. and we have responsibility to provide technology support with you forever.
d. Our engineers can provide basic formula and help customer to produce good quality food according customer’s detailed formula.
e.The spare parts We provide will at preferential price for an extended long time.
