Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > 100W 36V 2.8A Constant Voltage IP 67 CE Transformer LPV-100-36

100W 36V 2.8A Constant Voltage IP 67 CE Transformer LPV-100-36

Name: 100W 36V 2.8A Constant Voltage IP 67 CE Transformer LPV-100-36
Brand: LEYU 100w transformer, LEYU 100w 36v transformer
SKU: 113145199

100W 36V 2.8A Constant Voltage IP 67 CE Transformer LPV-100-36 thumbnail-1

100W 36V 2.8A Constant Voltage IP 67 CE Transformer LPV-100-36 photo-1

US$ 14.56 - 17.86 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

China

Brand Name:

LEYU 100w transformer, LEYU 100w 36v transformer

Model Number:

LPV-100-36

Contact Supplier Request Quote Chat Now

Yueqing Leyu Electric Automation Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin China

Brand Name LEYU 100w transformer, LEYU 100w 36v transformer

Model Number LPV-100-36

Output Power 51 - 100W

Output Type Single

Input Voltage Other, 180~264VAC

Output Voltage 36V

Output Frequency 25~100KHz

Output Current 2.8A

Specifications

100w transformer
1.Warranty:2 years
2.Certification:CE RoHS IP67
3.Over load protection
4.low cost,high reliability

100W 36V 2.8A Constant Voltage IP 67 CE Transformer LPV-100-36

Specification:

100W Single Output Waterproof Switching Power Supply LPV-100 series

MODEL		LPV-100-5	LPV-100-12	LPV-100-15	LPV-100-24	LPV-100-36	LPV-100-48
OUTPUT	DC VOLTAGE	5V	12V	15V	24V	36V	48V
	CURRENT RANGE	0 ~ 12A	0 ~ 8.5A	0 ~ 6.7A	0 ~ 4.2A	0 ~ 2.8A	0 ~ 2.1A
	RATED CURRENT	12A	8.5A	6.7A	4.2A	2.8A	2.1A
	RATED POWER	60W	102W	100.5W	100.8W	100.8W	100.8W
	RIPPLE & NOISE (max.) Note.2	80mVp-p	120mVp-p	120mVp-p	150mVp-p	150mVp-p	150mVp-p
	VOLTAGE TOLERANCE Note.3	±8.0%	±5.0%
	LINE REGULATION	±1.0%
	LOAD REGULATION	±6.0%	±2.0%
	SETUP, RISE TIME NOTE.6	2000ms, 25ms / 230VAC 2000ms, 25ms / 115VAC
	HOLD UP TIME (Typ.)	50ms/230VAC 16ms/115VAC at full load
INPUT	VOLTAGE RANGE NOTE.4	90 ~ 264VAC 127 ~ 370VDC
	FREQUENCY RANGE	47 ~ 63Hz
	EFFICIENCY (Typ.)	80%	85%	87%	88%	88%	89%
	AC CURRENT (Typ.)	2.2A/115VAC 1.2A/230VAC
	INRUSH CURRENT (Typ.)	COLD START 30A/115VAC 60A/230VAC
	LEAKAGE CURRENT	0.25mA / 240VAC
PROTECTION	OVER CURRENT NOTE.4	110 ~ 150% rated output power
		Protection type : Hiccup mode, recovers automatically after fault condition is removed
	OVER VOLTAGE	5.75 ~ 6.75V	13.8 ~ 16.2V	17.25 ~ 20.25V	27.6 ~ 32.4V	41.4 ~ 48.6V	55.2 ~ 64.8V
		Protection type : Shut down o/p voltage, re-power on to recover
ENVIRONMENT	WORKING TEMP.	-25 ~ +70°C (Refer to output load derating curve)
	WORKING HUMIDITY	20 ~ 90% RH non-condensing
	STORAGE TEMP., HUMIDITY	-40 ~ +80°C, 10 ~ 95% RH
	TEMP. COEFFICIENT	±0.03%/ (0 ~ 50°C )
	VIBRATION	10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
SAFETY &EMC(Note 4)	SAFETY STANDARDS	IP67 approved, Design refer to TUV EN60950-1,
	WITHSTAND VOLTAGE	I/P-O/P:3KVAC
	ISOLATION RESISTANCE	I/P-O/P:>100M Ohms / 500VDC / 25 / 70% RH
	EMC EMISSION	Compliance to EN55022 (CISPR22) Class B
	EMC IMMUNITY	Compliance to EN61000-3-2,-3
OTHERS	MTBF	703Khrs min. MIL-HDBK-217F (25°C)
	DIMENSION	1905135mm (LWH)
	PACKING	0.63Kg,20pcs/13.6Kg/0.51CUFT
