Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > Constant Voltage LDV-200-36 IP67 Design 200w 36v Waterproof LED Driver With 2 Years Warranty

Constant Voltage LDV-200-36 IP67 Design 200w 36v Waterproof LED Driver With 2 Years Warranty

Name: Constant Voltage LDV-200-36 IP67 Design 200w 36v Waterproof LED Driver With 2 Years Warranty
Brand: LEYU 200w 36v waterproof LED driver, LEYU 200w 36v waterproof LED driver
SKU: 113144523
Availability: InStock

Constant Voltage LDV-200-36 IP67 Design 200w 36v Waterproof LED Driver With 2 Years Warranty thumbnail-1

Constant Voltage LDV-200-36 IP67 Design 200w 36v Waterproof LED Driver With 2 Years Warranty photo-1

US$ 21.23 - 23.23 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

LEYU 200w 36v waterproof LED driver, LEYU 200w 36v waterproof LED driver

Model Number:

LDV-200-36V

Contact Supplier Request Quote Chat Now

Yueqing Leyu Electric Automation Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name LEYU 200w 36v waterproof LED driver, LEYU 200w 36v waterproof LED driver

Model Number LDV-200-36V

Output Power 101 - 200W

Output Type Single

Input Voltage Other, 180~264VAC

Output Voltage 36v 200w 36v waterproof LED driver

Output Frequency 25~100KHz

Output Current 5.5A 200w 36v waterproof LED driver

Constant voltage LDV-200-36 IP67 Design 200w 36v waterproof LED driver

Specification:

200W Single Output Waterproof Switching Power Supply LDV-200 series

Features:
High efficiency, High reliability, Low cost
Protections: Short circuit/Over load/Over voltage/High temperature
Waterproof grade: IP67
Working Frequency: 65 KHz
Suitable for LED lighten and moving sign applications.
2 years warranty

SPECIFICATION
OUTPUT
Model	LDV-200-5	LDV-200-12		LDV-200-24		LDV-200-36
DC Voltage	5V	12V		24V		36V
Rated Current	30A	16.5A		8.3A		5.5A
Current Range	0-30A	0-16.5A		0-8.3A		0-5.5A
Rated Power	150W	198W		199W		198W
Ripple & Noise	150mVp-p	150mVp-p		200mVp-p		200mVp-p
Voltage Tolerance	±1%	±1%		±1%		±1%
Inlet Stability	±0.5%	±0.5%		±0.5%		±0.5%
Load Stability	±0.5%	±0.5%		±0.5%		±0.5%
Setup, Rise, Hold Up Time	200ms,20ms,30ms/230VAC

INPUT
Voltage Range	180~264 VAC 47~63Hz;255~373VDC
AC Current	1.5A/230VAC
Efficiency	82%	82%		84%		85%
Inrush Current	Cold-start current 40A/230VAC

PROTECTION
Over Load	105%~135%
	Protection:Hiccup mode, recovers automatically after fault condition is removed
Over Voltage	15~17V		30~32V		42~44V
	Protection:Hiccup mode, recovers automatically after fault condition is removed
High Tem.	≥85℃
	Protection:cut off the output, recovers automatically after fault condition is removed

ENVIRONMENT
Working Temp., Humidity	-10℃~+60℃,20%~90%RH
Storage Temp., Humidity	-20℃~+85℃, 10%~95%RH
Temp. Coefficient	±0.03%/℃(0-50℃)
Vibration	10-500Hz,2G 10min,/1cycle,Period for 60min,Each axes

SAFETY
Withstand Voltage	I/P-O/P: 3KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC
Isolation Resistance	I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC

STANDARD
Safety Standard	EN61347-1 EN61347-2-13 IP67
EMC Standard	EN55015 EN61547 EN61000-3.4 CLASSB

OTHERS
Dimension	23012555(LWH)
Weight	2.42Kg

NOTE	1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance: includes set up tolerance, line regulation and load regulation.

What is our magic weapon for winning?
1.10 years experience for producing Electric Appliances.
2. Independent research and development ability, with 15 years experience of engineers.
3. No one we have, we have excellent!

Detailed photos :
