24v High Efficiency AC DC for LED Strip 60w Waterproof Led Driver

Name: 24v High Efficiency AC DC for LED Strip 60w Waterproof Led Driver
Brand: LEYU waterproof led driver
SKU: 113144049

US$ 7.5 - 8.5 MOQ: 1 Piece

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

LEYU waterproof led driver

Model Number:

LDV-60-24V

Yueqing Leyu Electric Automation Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name LEYU waterproof led driver

Model Number LDV-60-24V

Output Power 51 - 100W

Output Type Single

Input Voltage Other, 180~264VAC

Output Voltage 24V

Output Frequency 25~100KHz

Output Current 2.5A

Specifications

waterproof led driver
1.Warranty :2 years
2.Dimension:190*49*35mm
3.Brand Name :LEYU waterproof led driver

24v high efficiency AC DC for LED strip 60w waterproof led driver

Product Description

60W Single Output Waterproof Switching Power Supply LDV-60 series

SPECIFICATION
OUTPUT
Model	LDV-60-12	LDV-60-24
DC Voltage	12V	24V
Rated Current	5A	2.5A
Current Range	0-5A	0-2.5A
Rated Power	60W	60W
Ripple & Noise	120mVp-p	120mVp-p
Voltage Adj. Range	±10%	±10%
Voltage Tolerance	±1%	±1%
Inlet Stability	±0.5%	±0.5%
Load Stability	±0.5%	±0.5%
Setup, Rise, Hold Up Time	800s,50ms,10ms/115VAC 300ms,50ms,80ms/230VAC

INPUT
Voltage Range	170~250VAC 50-60Hz
AC Current	2A/115V 1A/230V
Efficiency	76%	79%
Inrush Current	Cold-start current 30A/115V 60A/230V

PROTECTION
Over Load	105%~150%
	plusing hiccup shutdown Reset:auto recovery

ENVIRONMENT
Working Temp., Humidity	-10℃~+60℃(Refer to output derating curve),20%~90%RH
Storage Temp., Humidity	-20℃~+85℃, 10%~95%RH
Temp. Coefficient	±0.03%/℃(0-50℃)
Vibration	10-500Hz,2G 10min,/1cycle,Period for 60min,Each axes

SAFETY
Withstand Voltage	I/P-O/P: 3KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC
Isolation Resistance	I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC

STANDARD
Safety Standard	UL1012TUV EN60950(IEC950,UL1950) Approved IP67
EMC Standard	CLSPR22(EN55022),IEC801-2,3,4,IEC555-2 Verification

OTHERS
Dimension	1555070mm(LWH)
Weight	0.56Kg
