CE Approved 1200w 12v 24v 48v High Power With Parallel Function SCN-1200-12 Switching Power Supply

CE Approved 1200w 12v 24v 48v High Power With Parallel Function SCN-1200-12 Switching Power Supply thumbnail-1
CE Approved 1200w 12v 24v 48v High Power With Parallel Function SCN-1200-12 Switching Power Supply photo-1
US$ 201.83 - 220.99 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
LEYU 1200W power supply
Model Number:
SCN-1200-12V/24V/48V
Contact Supplier Request Quote Chat Now
Yueqing Leyu Electric Automation Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name LEYU 1200W power supply
Model Number SCN-1200-12V/24V/48V
Output Power Other, >500W
Output Type Single
Input Voltage Other, 200~260V
Output Voltage 12v 24v 48v
Output Frequency 25~100KHz
Output Current 100A 50A 24A





CE approved 1200w 12v 24v 48v high power with parallel function SCN-1200-12 switching power supply













 1200W Single Output with Parallel Function     SCN-1200 series



Features:



AC input power suitable for the world



High efficiency and low operation temperature



Soft-start current can reduce the AC input impact effectively



With short -circuit and overload protection



Compact size, light weight



100% full-load burning test



Installed with EMI filter, minimum wave



SPECIFICATIONS

OUTPUT



Model

SCN-1200-12

SCN-1200-15

SCN-1200-24

SCN-1200-48

DC Voltage

12V

15V

24V

48V

Rated Current

100A

80A

50A

25A

Current Range

0-100A

0-80A

0-50A

0-25A

Rated Power

1200W

1200W

1200W

1200W

Ripple & Noise

120mVp-p

1500mVp-p

240mVp-p

480mVp-p

Voltage Adj. Range

10~13.2V

13.5~18V

20~26.4V

41~56V

Voltage Tolerance

±1%

±1%

±1%

±1%

Inlet Stability

±0.5%

±0.5%

±0.5%

±0.5%

Load Stability

±0.5%

±0.5%

±0.5%

±0.5%

Setup, Rise, Hold Up Time

1.5s,50ms,20ms at full load





INPUT



Voltage Range

200-260VAC   47~63V

AC Current

11A/230VAC

Efficiency

83%

85%

85%

87%

Inrush Current

120A/230V

Leakage Current

<3.5mA/240VAC





PROTECTION



Over Load

Current limiting delay shutdown o/p voltage ,repower onto recover

Over Temp.

TSW1 (Power transistor when temp>100℃ shut down O/P voltage re-power on to recover





ENVIRONMENT



Working Temp., Humidity

-10℃~+65℃(Refer to output derating curve),20%~90%RH

Storage Temp., Humidity

-20℃~+85℃, 10%~95%RH

Temp. Coefficient

±0.03%/℃(0~50℃)

Vibration

10~200Hz,2G 10min,/1cycle,Period for 60min,Each X.Y.X axes





SAFETY



Withstand Voltage

I/P-O/P , I/P-F/G 1500VAC

Isolation Resistance

I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC





STANDARD



Safety Standard

Meet UL1950requirement(Not apply for the mark)

EMC Standard

CISPR22(EN55022),IEC1000-4,2,3,4,5,6,8,11 IEC1000-3-2





OTHERS



Dimension

291*132*132mm(L*W*H)

Weight

5.0Kg



 CE approved 1200w 12v 24v 48v high power with parallel function SCN-1200-12 switching power supply



CE approved 1200w 12v 24v 48v high power with parallel function SCN-1200-12 switching power supplyCE approved 1200w 12v 24v 48v high power with parallel function SCN-1200-12 switching power supply







Advantages

CE approved 1200w 12v 24v 48v high power with parallel function SCN-1200-12 switching power supply

1.  Reply your inquiry in 24 working hours

2.  Customized design is avalible, OEM and ODM are welcomed

3.  Delivery the goods to our customers all over the world with speed and prscision

4.  Offer customers the lowest price with high quality power supply





Certifications

CE approved 1200w 12v 24v 48v high power with parallel function SCN-1200-12 switching power supply

CE approved 1200w 12v 24v 48v high power with parallel function SCN-1200-12 switching power supply



Company Information

LEYU Electric Automation Co.,Ltd. is a manfacturer specialized in developing, producing Power Supply/LED Driver/DC DC Converter in China for 10 years experience.We own CE, RoHS, CCC, and ISO9001 certification.

We are striving to provide the first-class products and service for you.





After-sale seivice

1. 2 years' warranty

2. Free tech support

3. Parts replacement for free
