LEYU 2 Year Warranty High Efficiency SD-150B-24 150W 24V dc to 24V dc converter power supply
- 10000 Piece / Pieces per Month
- Ningbo/ Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- ME Series Modules High Stability High Voltage Power Supply for Microchannel Plates
- MMC Series DC High Stability Voltage Power Supply for Microchannel Plates (100V-600V,0.1W)
- Brand new power box 640C0022G01 York control system motherboard power supply GLC75D-CVG
- Power Supplies TVD1.3-15-03 Original Stock
- 10W 2.5KV Isolation Wide Input AC/DC Converters
- 30W Wide Voltage Input DC/DC Converters power supply
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | Leyu 24v dc to 24v dc converter | Model Number: | SD-150B-24 24v dc to 24v dc converter |
Output Power: | 101 - 200W | Output Type: | Single | Input Voltage: | Other, 18-36V |
Output Voltage: | 24V 24v dc to 24v dc converter | Output Frequency: | 47-63HZ | Output Current: | 6.25A 24v dc to 12v dc converter |
Product Description
2 Year Warranty High Efficiency 150W 24v dc to 24v dc converter
150W Single Output DC-DC Converter SD-150 series
Features :
2:1 wide input range
Protections: Short circuit / Overload / Over voltage
1500VAC I/O isolation
Built-in EMI filter, low ripple noise
100% full load burn-in test
24V and 48V input voltage design refer to LVD
Low cost
High reliability
2 year warranty
SPECIFICATION | |||||||
OUTPUT |
| ||||||
Model | SD-150B-12 | SD-150C-12 | SD-150D-12 | SD-150B-24 | SD-150C-24 | SD-150D-24 | |
DC Voltage | 12V | 24V | |||||
Rated Current | 12.5A | 6.3A | |||||
Current Range | 0 ~ 12.5A | 0 ~ 6.3A | |||||
Rated Power | 150W | 151.2W | |||||
Ripple & Noise | 120mVp-p | 150mVp-p | |||||
Voltage Adj. Range | 11 ~ 16VDC | 23 ~ 30VDC | |||||
Voltage Tolerance | ±1.0% | ±1.0% | |||||
Line Regulation | ±0.5% | ±0.3% | |||||
Load Regulation | ±0.5% | ±0.3% | |||||
Setup, Rise Time | 2s, 50ms at full load | ||||||
Hold Up Time | 24ms(only D mode) at full load | ||||||
|
| ||||||
INPUT |
| ||||||
Voltage Range | B:19 ~ 36VDC C:36 ~ 72VDC D:72 ~144VDC or 85 ~ 132VAC | ||||||
Efficiency | 75% | 77% | 79% | 77% | 80% | 82% | |
DC Current | 6.8A/24V | 3.4A/48V | 2.7A/96V | 6.8A/24V | 3.4A/48V | 2.7A/96V | |
Inrush Current | D:22.5A/96VDC | ||||||
Leakage Current | <0.75mA / 120VAC (SD-150D) | ||||||
|
| ||||||
PROTECTION |
| ||||||
Over Load
| 105 ~ 135% rated output power | ||||||
Protection type: Hiccup mode, recovers automatically after fault condition is removed | |||||||
Over Voltage | 16.8V ~ 20V/10% LOAD | 31.5 ~ 37.5V/10% LOAD | |||||
Protection type: Hiccup mode, recovers automatically after fault condition is removed | |||||||
|
| ||||||
ENVIRONMENT |
| ||||||
Working Temp. | -10 ~ +60℃ (Refer to “Derating Curve”) | ||||||
Working Humidity | 20 ~ 90% RH non-condensing | ||||||
Storage Temp., Humidity | -20 ~ +85℃, 10 ~ 95% RH | ||||||
Temp. Coefficient | ±0.03%/℃ (0 ~ 50℃) | ||||||
Vibration | 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes | ||||||
|
| ||||||
SAFETY & EMC |
| ||||||
Safety Standards | IEC60950-1 CB | ||||||
Withstand Voltage | I/P-O/P: 1.5KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC | ||||||
Isolation Resistance | I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃ / 70% RH | ||||||
EMC Emission | Compliance to EN55022 (CISPR22) Class B | ||||||
EMC Immunity | Compliance to EN61000-4-2,3,4,6,8, light industry level, criteria A | ||||||
|
| ||||||
OTHERS |
| ||||||
Dimension | 199*110*50mm (L*W*H) | ||||||
Weight | 0.86Kg | ||||||
Packing | 16pcs/14.5Kg/0.95CUFT |
FAQ -power inverter
1. Do you accept OEM for the power inverter ?
Yes. we do .
2 .What certificated do you have ?
CE RoHS ISO9001
3.How to Contact Us ?
Send your inquiry Details in the below, Click "Send" Now !
