LED Frame Full Color Screen P37.5 Gridding LED Sreen/ Advertising LED Marquee Signs

Name: LED Frame Full Color Screen P37.5 Gridding LED Sreen/ Advertising LED Marquee Signs
Brand: SZLCCL
SKU: 113123721

US$ 400 - 800 MOQ: 1 Square Meter

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

SZLCCL

Model Number:

P37.5

Shenzhen LCCL Opto-Electronic Science & Technology Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name SZLCCL

Model Number P37.5

Usage Outdoor

Tube Chip Color Full Color

Display Function Video

Pixels Other, 37.5mm

LED Frame Full Color Screen P37.5 Gridding LED Sreen/ Advertising LED Marquee Signs

Technical Data:

Pixel Pitch	37.5mm
Pixel Configuration	1R1G1B
LED Encapsulation Method	DIP 546
Module Resolution	16dots x 8dots
Module Size	600mm x 300mm
Module Weight	1.25KG
Pixel Density	711 dots/m2
Power Consumption	Max.:210W/m2 Average: 105W/m2
Brightness	≥5000cd/m2
Driving Method	Static state
Control Mode	Video frequency synchronization
Optimal Viewing Distance	37.5m
Gray Scale	Recommended 16384 level
Refresh Frame Frequency	≥300Hz
Blind Spot Rate	<0.0001
Brightness Control	256 Grade
View Angle	Horizontal 110° Vertical 55°
Contrast	100 levels adjustable
Effective Control Distance(without relay)	Unshielded Twisted-Pair net line transmission distance 100M
View Angle	Horizontal 110° Vertical 55°
Contrast	100 levels adjustable
Earth Leakage Current	<2mA
MTBF	>5000Hours
Lifespan	>100000Hours
Power Supply Mode	AC220V/50HZ or AC110V/60HZ
Protection Level	Front IP65 Back IP55
Humidity	10%~90%
Operating System	Windows98/me/2000/NT/XP
Operation Environment Temperature	Storage:-40°C~+85°C Operation:-20°C~+45°C
