P6 Full Color Curve Cylindrical Led Display Screen Price

P6 Full Color Curve Cylindrical Led Display Screen Price thumbnail-1
P6 Full Color Curve Cylindrical Led Display Screen Price photo-1
Negotiable MOQ: 1 Square Meter (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SZLCCL
Model Number:
P6
Contact Supplier Request Quote Chat Now
Shenzhen LCCL Opto-Electronic Science & Technology Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shekou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SZLCCL
Model Number P6
Usage Indoor
Tube Chip Color Full Color
Display Function Video
Pixels Other, 6mm

Specifications

1.High-quality LED
2.Ultra bright
3.Perfect anti-static precautions
4.High pixel density
5.No Flickering

P6 Full Color  Curve Cylindrical led display screen price



Cabinet Structure:

P6 Full Color Curve Cylindrical led display screen price



Side View:



P6 Full Color Curve Cylindrical led display screen price



Technical Parameter:



Description Technical parameter
Unit module Module size 192*96mm
Pixel pitch 6mm
Pixel density 27777dots/m2
Pixel configuration 1R1G1B
Led specification 3528 SMD 3 in 1
Pixel resolution W:192dots*H:96dots
Cabinet Dimension 768mm*768mm*150mm
Quantities of module 32pcs
Power supply 4pcs
Thermal discharge Fan*2pcs
Total weight 40kg
Best viewing angle 2-100m
Temperature Storage: -35°C~+85°C
Working: -35°C~+85°C
Thickness 15cm can adjustable
Remarks: cabinet size can changed, upon project need.
Power Working voltage AC220V/110V±10%
Average power consumption 200-300W
Max. Power consumption ≤320W/sqm
Current ≤20mA(single LED)
Control system CPU Pentium4 or above
Operating system WIN98/2000/NT/XP
Control method Synchronization
Main technical parameter Driving device 1/16scanning
Drive type Constant Current driver IC
Refresh frequency ≥300Hz
Grey scale/colors 256 levels of each color(R/G/B)/16.7M color
Brightness of white balance More than 2200cd/sqm
Brightness adjustment 256 levels of each color(R/G/B)by software
Operating ambient humidity 10%--95%
Video signal PAL/NTSC
Control system DVI display card+full color controller card
MTBF ≥10,000hours
Life span ≥100,000hours
Flatness Tolerance of interpixel ≤0.3mm
Tolerance of modules clearance≤0.6mm
Power switch Automatic switch
Display mode 1024*768
Communication distance Unshielded twisted pair net line transmission distance 100m, max transmission distance 200m.
Multi-mode Optic fiber transmission distance 500m;Single-mode optic fiber transmission distance 10KM
Software LED media player





The packing way:



P6 Full Color Curve Cylindrical led display screen price
