Help CenterUV Sterilizer 16W
Related Products
Material:#304/316 stainless steel
UV lamp pwer:25W, Chinese UV lamp/Philips UV lamp
UV lamp life: 9000 hrs
Inlet/outlet: 1/2" male thread
Size:A:910MM, B: 85MM, Diameter: 63.5MM
Water treatment: 6GPM,
Max Operating pressure: 10bar/145psi
Application: drinking water, public places, food processing etc.
1. High Efficiency
Lightbest sterilizer has the superior UV germicidal lamp inside, which made from high purity quartz tube, keeps the UV transmittance over 90%.
<img src="/kf/HTB1qE4bIpXXXXXmXFXXq6xXFXXXH/223522809/HTB1qE4bIpXXXXXmXFXXq6xXFXXXH.jpg" alt="6W UV Sterilizer 0.5GPM UV Filter Stainless Housing for kitchen hood" ori-width="800" ori-height="623">
By emitting UV light with the peak wavelength of 253.7nm (commonly called 254nm or Ozone-free/L), Lightbest sterilizer kills 99-99.99% microorganisms including bacteria, viruses, fungi and protozoa such as cryptosporidium, giardia, SARA, H5N1, etc. within 1 to 2 seconds.
| Species | Name | 100%kill(s) | Name | 100%kill(s) |
| Bacteria | Anthraces | 0.30 | Tuberculosis | 0.41 |
| Diphtheria | 0.25 | Vibrio Choleria | 0.64 | |
| Clostridium Botulism | 0.80 | Pseudo monas Bacteria | 0.37 | |
| Tetanus | 0.33 | Salmonella | 0.51 | |
| Dysentery Bacillus | 0.15 | Fever Bacteria | 0.41 | |
| Cobibacillu | 0.36 | Bacillu Typhi murium | 0.53 | |
| Hook-side Pylon Bacillus | 0.20 | Shigella | 0.28 | |
| Legion Ella | 0.20 | Staphylococcus | 1.23 | |
| Micro co | 0.4-1.53 | Streptococcus | 0.45 | |
| Virus | Adenovirus | 0.10 | Influenza Virus | 0.23 |
| Phagocyte Cell Virus | 0.20 | Polio Virus | 0.80 | |
| Coxsackie Virus | 0.08 | Rota Virus | 0.52 | |
| ECHO Virus | 0.73 | Tobacco Mosaic Virus | 16.00 | |
| ECHO Virus 1 | 0.75 | Hepatitis B Virus | 0.73 | |
| Mold Spore | Aspergillums Niger | 6.67 | Soft Spores | 0.33 |
| Aspergillums | 0.73-8.80 | Penicillium | 2.93-0.87 | |
| Dung Fungi | 8.00 | Penicillium Chrysogenum | 2.00-3.33 | |
| Mucor | 0.23-4.67 | Other Fungi Penicillium | 0.87 | |
| Water Algae | Blue-green algae | 10-40 | Paramecium | 7.30 |
| Chlorella | 0.93 | Green Algae | 0.22 | |
| Line Ovum | 3.40 | Protozoan | 4-6.70 | |
| Fish Disease | Fung 1 Disase | 1.60 | Infectious Pancreatic Necrosis | 4.00 |
| Leukodermia | 2.67 | Hemorrhagic | 1.60 |
2. No Secondary Pollution
By using Lightbest sterilizer, there is no need to add chemical bactericide, avoiding undesirable color, taste or odor. It does not generate harmful byproducts, brings no secondary pollution to water and ambient environment.
<img src="/kf/HTB1Mh37IXXXXXc6XFXXq6xXFXXXv/223522809/HTB1Mh37IXXXXXc6XFXXq6xXFXXXv.jpg" alt="6W UV Sterilizer 0.5GPM UV Filter Stainless Housing for kitchen hood" ori-width="800" ori-height="433">
The ultraviolet photons harm the DNA molecules of living organisms in different ways. In one common damage event, adjacent thymine bases bond with each other, instead of across the “ladder”. This “thymine dimer” makes a bulge, and the distorted DNA molecules will not function properly.
3. Wide Application
Lightbest sterilizers are commonly seen in various water treatment systems:
a) Residential water purification, to bring health and safety to our daily life;
b) Industrial water sterilization, to supply treated water for different needs, such as clean water for irrigation and fish tank, cooling water for production;
c) Waste water reuse, to avoid sewage pollution and increase utilization of water, and make the earth a better place for our children.
<img src="/kf/HTB13V35IXXXXXatXVXXq6xXFXXXO/223522809/HTB13V35IXXXXXatXVXXq6xXFXXXO.jpg" alt="6W UV Sterilizer 0.5GPM UV Filter Stainless Housing for kitchen hood" ori-width="800" ori-height="876">
| Model No. | Flow rate | Inlet/Outlet | Lamp power (w) | Total Power (w) | Lamp Model | Quartz Sleeve |
Reactor size (cm) |
|
| m3/h | GPM | |||||||
| SUV-G1S | 0.1 | 0.5 | Female 1/4" | 6 | 8.25 | GPH212T5L/4 | QS23200245 | Ø50.8*260 |
| SUV-G1 | 0.2 | 1 | 11 | 15.125 | GPH212T5L/4 | QS23200245 | Ø50.8*260 | |
| SUV-G1L | 0.2 | 1 | 12 | 16.5 | GPH265T5L/4 | QS23200295 | Ø50.8*315 | |
| SUV-G2 | 0.4 | 2 | Male 1/2" | 16 | 22 | GPH330T5L/4 | QS23200360 | Ø63.5*370 |
| SUV-G6 | 1.4 | 6 | 25 | 34.375 | GPH550T5L/4 | QS23200580 | Ø63.5*508 | |
| SUV-G7 | 1.6 | 7 | 28 | 38.5 | GPH620T5L/4 | QS23200580 | Ø63.5*590 | |
| SUV-G8 | 1.8 | 8 | Male 3/4" | 30 | 41.25 | GPH645T5L/4 | QS23200870 | Ø63.5*885 |
| SUV-G10 | 2.3 | 10 | 40 | 55 | GPH843T5L/4 | QS23200900 | Ø63.5*950 | |
| SUV-G12 | 2.7 | 12 | 55 | 75.625 | GPH910T5L/4 | QS23200940 | Ø63.5*965 | |
| SUV-G24S | 5.5 | 24 | Male 1"/flange | 110 | 151.25 | Ø108*965 | ||
| SUV-G24 | 5.5 | 24 | 110 | 151.25 | Ø108*965 | |||
| SUV-G36S | 8 | 36 | Male 1 1/2"/flange | 165 | 226.875 | Ø133*965 | ||
| SUV-G36 | 8 | 36 | 165 | 226.875 | Ø133*965 | |||
| SUV-G48S | 11 | 48 | 220 | 302.5 | Ø133*965 | |||
| SUV-G48 | 11 | 48 | 220 | 302.5 | Ø133*965 | |||
| SUV-G72 | 16 | 72 | Male 2"/flange | 330 | 453.75 | Ø168*965 | ||
| SUV-G96 | 22 | 96 | Male 3"/flange | 440 | 605 | Ø219*965 | ||
| SUV-G120 | 30 | 120 | Male 4"/flange | 550 | 756.25 | Ø275*965 | ||
| SUV-G144 | 33 | 144 | 660 | 907.5 | Ø275*965 | |||
4. Easy Installation and Cost-effective
Lightbest sterilizer occupies a small area, you can install in-line or hang-on-tank to suit your tank. And for the cost, it only needs less than half of chlorine disinfection in kiloton water treatment.
<img src="/kf/HTB19MtdIpXXXXcqXpXXq6xXFXXXx/223522809/HTB19MtdIpXXXXcqXpXXq6xXFXXXx.jpg" alt="6W UV Sterilizer 0.5GPM UV Filter Stainless Housing for kitchen hood" ori-width="800" ori-height="496">
5. Long Life
Lightbest sterilizer, by using the polished 304 stainless steel housing, quartz lamps are safe inside, which improves disinfection efficiency and guarantee long life. Normally, the lamp can work more than 9000 hours.
<img src="/kf/HTB1AZM_IXXXXXaSXVXXq6xXFXXXM/223522809/HTB1AZM_IXXXXXaSXVXXq6xXFXXXM.jpg" alt="6W UV Sterilizer 0.5GPM UV Filter Stainless Housing for kitchen hood" ori-width="800" ori-height="552">
Lightbest provided: OEM service
Buyer Logo /Label
Custom Design Service
Guarantee:
A: Manufacture is to ISO9001:2000 standard.
B: Product is guaranteed for 12 months after lamp purchase.
C: According to the International Standard:AQL tolerance is within 2% of the total quantity per order.
D: If AQL tolerance exceeds 2%, Lightbest will refund the buyer at 1:1 rate; OR an amount equal to the UQL value will be deducted from the next order.
E: 2% of products are added by Lightbest (at no extra charge) to the ordered quantity for back-up purposes.
Lightbest concentrates on water purification treatment and supplies customers with one-stop service and solution on water treatment fields. We specialize in UV germicidal lamps, UV water sterilizers, electronic ballasts, booster pumps, ion exchange resin, FRP tanks, PP filter etc., and adhere on the principle of fighting, upholding, sharing and win-win together. We have been a supplier of water treatment with high-quality products, perfect service, professional operation and reasonable price both in China and the globe.
