Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > Silent Generator Diesel Engine Water Proof Deutz Engine Good Quality

Silent Generator Diesel Engine Water Proof Deutz Engine Good Quality

Name: Silent Generator Diesel Engine Water Proof Deutz Engine Good Quality
Brand: Huachai
SKU: 113029803
Availability: InStock

Silent Generator Diesel Engine Water Proof Deutz Engine Good Quality thumbnail-1

Silent Generator Diesel Engine Water Proof Deutz Engine Good Quality photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Hebei, China

Brand Name:

Huachai

Model Number:

100GF

Contact Supplier Request Quote Chat Now

Hebei Huabei Diesel Engine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

tianjin

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hebei, China

Brand Name Huachai

Model Number 100GF

Output Type AC Three Phase

Speed 1500rpm

Frequency 50HZ

Rated Power 100KW/125KVA

Rated Voltage 400/230V

Rated Current 180A

Engine Features:

1.Deutz brand diesel engine, single cylinder, single head, AC three phase, high-speed 4-stroke,V-90°shape

2.Turbocharged, inner oil pipe, inner water channel, four valve, central top-mounted 8 hole fuel injector

3.Electronic Governor

4.Bosch/Weifu Fuel injection pump, electronic motor starting system

5.Forged steel crankshaft ( imported from Deutz AG Germany), cast iron cylinder and replaceable wet type cylinder liner, crankshaft(imported from Deutz AG Germany), main bearings and big end bearings (imported from Deutz AG Germany)

Alternator Features:

1.Meccalte/Stamford/Customized

2.Brushless, 4 poles,rotation magnet, IP23(NEMA1)4.H class insulation system

Control Panel:Deep Sea

1.Automatic control panel, LCD display

2.Emergency stop

Generator-set Specification Data
Generator-set		Diesel Engine (DEUTZ)		Alternator (Stamford)
Model	100GF	Model	F8L413F	Model	UCI274E
Rated prime power	100KW	Prime power	117KW	Rated power	112KW
Standby. power	110KW	Stand power		Rated voltage	400V/230V
Rated voltage	400/230V	Rated speed	1500rpm	Efficiency	91.70%
Rated frequency	50Hz	No. of Cylinder	8	Rated current	202A
Rated currency	180A	Bore/stroke	125/130	Power factor	0.8
Power factor	0.8	Cylinder arrangement	V	Frequency	50Hz
Steady state volt deviation	≤±5%	Fuel consumption	217g/kwh	Protection/ insulation	IP23/H
Steady state frequency	≤2.5%	Start mode	24V electrical	Exciting way	brushless self-exciting
Frequency drop scope	≤8%	Governor	mechanical	Weight	455kg
Phase	three phase	Aspiration type	Naturally aspirated
Base Frame	steel	Cooling way	air cooled
Dimension (mm)	2200×1100×1100	Displacement	12.763L
Weight	1550kg	Weight	770kg
Running Condition:According:GB/T2820;Altitude:0~1000m;Ambient temperature:-35~40℃; Relative humidity :95%
Standard scope of supply:Generator-set assembly(diesel engine, alternator, air filter, oil filter, fuel filter, silencer elbow, battery, Connection lines, circuit breaker, bracket)
Option :base oil tank, independent oil tank, Assistant starting system when low temperature, Intelligent control system(including Weidian, Comap, Deep sea, etc). Different alternator brands available. One phase is optional.
Control system function:start and stop function. Panel: voltage, current, frequency, power factor, power, oil pressure, battery voltage, start times, gen-set running hours, temperature, etc. Failure protection(alarm and stop)function:over speed/speed signal loss alarm, low oil pressure alarm, high cylinder temperature stop, low battery voltage alarm, stop failure alarm, emergency stop alarm, VAC/frequency over limit alarm, currency/power over load alarm, voltage unstable alarm, currency unstable alarm, belt broken alarm, etc.
