1000M Port Industrial Managed POE Media Converter/1000Base-FX to 1000Base-TX RJ 45 Port Fiber Optic

Description

   This series converters are designed to meet the massive needs for Gigabit network deployment and able to extend a copper based Gigabit network via fiber cable to a maximum distance up to 80KM.
   This series converters are fully compliant with IEEE802.3z & 802.3ab standards. It can be installed into a Standard Converter Chassis. The installation & operation procedures are simple & straightforward. Operation status can be locally monitored through a set of Diagnostic LED located in the front panel.

 Features

• 10/100/1000Base-TX to 1000BASE-FX Converter
  Standard : IEEE 802.3z & 802.3ab
  Interface: 1 x RJ-45 connector / 2 x SFP Slot
  MDI/MDIX Auto-Crossover supported
  LED: Power , DUP,FP-LINK,RX,1000,TX
  Plug-and-Play installation
  Support Jumbo Frame (64-9216 Byte)
  Support Voltage Monitor

  Dimension :

  External power supply : 94 x 70.5 x 26.5 mm (W x D x H)

  Internal power supply : 140.5 x 111 x 30 mm (W x D x H)



•


  Item		Specification/Term
  1	Item number	BT-950SFP series
  2	Standard Protocol	IEEE802.3u,10/100/1000Base-T,1000Base-SX/LX,IEEE802.3ah, IEEE802.3z/ab
  3	Flow control	IEEE802.3x port flow control and back pressure control
  4	Transmission speed	10/100/1000M auto-negotiation
  5	Transmission mode	Full-duplex/semi duplex(auto-negotiation)
  6	Conversion mode	Storage transmission
  7	MAC address	VLAN  4K
  8	Buffer space	128KB
  9	Packet length	Storage transmission:9728Bytes,straight-through,infinite.
  10	Time-delay	9.6us
  11	Bit error rate	<1/1000000000
  12	MTBF	100,000 hours
  13	Power supply	Outside: 5V DC 1A  ;  Build-in: 110~265V AC 48V DC
  14	Power dissipation	<2.5W
  15	Interface	Electric port: RJ45,Fiber port:SC/FC or SFP
  16	Twisted-pair cable	Cat.5 UTP cable
  17	Multimode fiber	50/125, 62.5/125um
  18	Single mode fiber	9/125, 10/125um
  19	Wavelength	850nm/1310nm/1550nm
  20	Transmit distance
  	1)Dual fiber multimode	550m
  	2)dual fiber single mode	20/40/60/80/100/120Km
  	3)single fiber single mode	20/40/60/80Km
  	4)Cat.5 twisted-pair	100m
  21	Operating temperature	0~60℃
  22	Storage temperature	-20~70℃
  23	Humidity	5%~90%  (no condensation)

Product Pictures : SFP Ethernet Fiber Media Converter
