China Xj250 Truck-mounted Drilling Rig

China Xj250 Truck-mounted Drilling Rig thumbnail-1
China Xj250 Truck-mounted Drilling Rig photo-1
US$ 58,000,000 - 120,000,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Rotary Drilling Rig
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Lijin Hongsheng Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Rotary Drilling Rig
Power Type Diesel
Place of Origin Shandong, China
Brand Name hongsheng
Certification API
Warranty 12month
After-sales Service Provided Engineers available to service machinery overseas

Specifications

meet api certification
new condation and fast delivery
best price and service
15years work in kazakhstan
hot sale in China



1 , powered by a Caterpillar engine and Allison hydraulic transmission , a reasonable match , stable performance , strong power and high efficiency. Compact drive unit ministries structure, reasonable layout.

2 , down from the tank using a large multi- shaft center distance can be passed to the platform power winch, front axle or rear axle and interlocking respectively .

3, the winch brake rod using a complex mechanism , reducing the intensity of the driller 's operation , the brake hub forced circulation cooling , favorable winch work to ensure that the main brake sensitive and reliable. Using two chamber Pneumatic water-cooled auxiliary brake , broadening the auxiliary brake function, and enhance the role of the auxiliary brake .

4 , the turntable can achieve positive , rewind, and can adapt to a variety of drill pipe rotary operations , equipped with anti- torque release device to ensure the safe release of the drill pipe deformation energy .

5 , Derrick is a front opening , double four-point support package shaped derrick mast , telescopic hydraulic cylinder double put the overall effect , easy operation , safe and reliable.

6 , for the spin -up rig structure, function complete, easy lifting and transportation , table size and height according to user requirements to develop.

7 , perfect solid control , well control , pressure manifold and auxiliary equipment to meet user requirements,

8 , relocation moving very fast and convenient . Carrier vehicle both to ensure flexible steering , and to ensure adequate capacity, through the good , and good off-road . In order to meet the needs of our customers , our company truck-mounted Rig , the existing five models ready for you to choose

To meet the different needs of customers, the following five models for you to choose the car rig. ZJ10, ZJ15, ZJ20, ZJ30, ZJ40 truck-mounted drilling rig



Model ZJ10/900CZ ZJ15/1125CZ ZJ20/1580CZ ZJ30/1700CZ ZJ40/2250CZ
lling depth m (41/2 "drill)) 1000 1500 2000 3000 4000
Overhaul depth m (31/2 drill) 3200 4500 5500 6500 7000
The maximum hook load KN 900 1125 1580 1800 2250
Hook speedm/sm/s 0.2~1.4
Derrick heightmm 29 32 35 36/38 36/38
Derrick form Mast shape/TD> Mast shape Mast shape Shaped or erect masts Shaped or erect masts
Engine Model CAT3406 OrC-9 ATAAC CAT3408 DITA OrC-15 ATAAC CAT3412DITA OrC-16ATAAC 2×CAT3408 DITA Or2×C-15ATAAC 2×CAT3408 DITA Or2×C-15ATAAC
Engine powerkw 269
Or
261		 354 485Or492 2×354 2×396Or2×392
Liquid Gearbox S5600HR S5600HR S6610HR 2×S5610HR 2×S5610HR
Transmission Type Hydraulic + Mechanical
Traveling system 3×4 4×5 4×5 4×5/5×6 5×6
Main rope diameter mm 26 26 29 32 32
Hook tour car models YG90 YG110 YG160 YG180 YG225
Faucet Model SL110 SL135 SL160 SL225 SL225
Turntable models ZP175 ZP175 ZP175 ZP205/ZP275 ZP205/ZP275
Chassis Type XD40/8×6 XD50/10×8 XD60/12×8 XD70/14×8 XD70/14×8
Approach / departure angle 26°/18°
Minimum ground clearance mm     311
Max.gradeability 30% 26% 26% 26% 26%
Minimum turning diameter m 28 30 38 41 41
Movement of Dimensionsm 16.7×2.8×4.2 18.8×2.85×4.3 20.5×2.85×4.45 22.3×3×4.45 22.3×3×4.48
Host quality kg 42000 50000 58000 76000 78000
Accessories Qualitykg 15000 20000 24000 32000 34000

 China xj250 truck-mounted drilling rig
