Help Center2014 Hot Sales Oil Well Rig Drilling Rig
Related Products
-
API AC Variable Frequency Electric Drive Drilling RigUS$ 492,000,000 - 690,000,000MOQ: 1 Set -
New Condation and API Electromechanical Combination Drive RigsUS$ 492,000,000 - 690,000,000MOQ: 1 Set
-
API Standard Mechanical Compound Drive RigUS$ 492,000,000 - 690,000,000MOQ: 1 Set
-
API and New Condation 3000M Drilling RigsUS$ 492,000,000 - 690,000,000MOQ: 1 Set
-
API Standard New 4000M Drilling RigsUS$ 492,000,000 - 690,000,000MOQ: 1 Set
Specifications
1.Modular design,Diesel-driven2.Hydraulic drive, mechanical drive, electric drive
3.Can be equipped with wellhead equipment
1 , powered by a Caterpillar engine and Allison hydraulic transmission , a reasonable match , stable performance , strong power and high efficiency. Compact drive unit ministries structure, reasonable layout.
2 , down from the tank using a large multi- shaft center distance can be passed to the platform power winch, front axle or rear axle and interlocking respectively .
3, the winch brake rod using a complex mechanism , reducing the intensity of the driller 's operation , the brake hub forced circulation cooling , favorable winch work to ensure that the main brake sensitive and reliable. Using two chamber
Pneumatic water-cooled auxiliary brake , broadening the auxiliary brake function, and enhance the role of the auxiliary brake .
4 , the turntable can achieve positive , rewind, and can adapt to a variety of drill pipe rotary operations , equipped with anti- torque release device to ensure the safe release of the drill pipe deformation energy .
5 , Derrick is a front opening , double four-point support package shaped derrick mast , telescopic hydraulic cylinder double put the overall effect , easy operation , safe and reliable.
6 , for the spin -up rig structure, function complete, easy lifting and transportation , table size and height according to user requirements to develop.
7 , perfect solid control , well control , pressure manifold and auxiliary equipment to meet user requirements,
8 , relocation moving very fast and convenient . Carrier vehicle both to ensure flexible steering , and to ensure adequate capacity, through the good , and good off-road . In order to meet the needs of our customers , our company truck-mounted
Rig , the existing five models ready for you to choose . ZJ10, ZJ15, ZJ20, ZJ30, ZJ40 truck-mounted drilling rig .
Oil Rig Model |
ZJ50J |
The name of the scope of drilling deep (127mm drill pipe) |
5000 |
Maximum hook set (kN) |
3,150 |
Drilling diameter rope (inch) |
1 3/8" |
Derrick effective height / type |
44.8m /K |
Diamond Height (m) |
9 |
Rated input power winch (kw) |
1100 |
Winch file number |
Two respectively stepless speed regulation |
