Home > Products > Dryer/Vaccum Drying Machine/Oven > JB Series Stainless Steel Double Cone Rotary Vacuum Drier for Sale
JB Series Stainless Steel Double Cone Rotary Vacuum Drier for Sale
- 5 Set / Sets per Month
- Shanghai
- T/T
- seamless softgel capsule machine for the beads and aroma mini ball production
- Latest AI Algorithm High Efficiency Visual Inspection Machine Equipment for Glass and PET Plastic Bottles Preforms
- Advanced High Efficiency AI Visual Quality Analyzer for Grains and Nuts Classification Grading machine
- Factory Price High Efficiency AI Visual Inspection Machine for Caps Defects Detection
- High Precision Automatic AI Vision Defect Inspection Machine for Plastic PET PP PE Bottles
- Automatic High Speed AI Visual Inspection Machine for Defects Food and Beverage Package
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | JINBAO | Model Number: | JB SERIES |
Application: | Other, Granules, Drying machine | Type: | Drying Machine | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Main Usage:
This dryer is suitable to the vucuum drying for power or granule materials of the lines of medicine, foodstuff, and chemical, etc, specially for the drying of following materials including thermal sensitive, easy oxidation, and the one that its crystal cannot be destructed, as well as the one which the solvent inside should be recollected or any stimulated or noxious materials.
Specity:
When the dryer vessel rotated, the heat-receiving surface of target materials are to be replaced every moment to quick the drying speed so that the products inside are ded evenly. Mean while, it is heated indirectly to avoid it being contaminated. Others include no dead angle inside, easy operating and cleansing, the optimized sealing design with, better seal effect, as well as very convenient maintenance etc.
Technical Data:
Model | SZG-100 | SZG-350 | SZG-500 | SZG-750 | SZG-1000 | SZG-1500 | SZG-2000 | |
Total volume (L) | 100 | 350 | 500 | 750 | 1000 | 1500 | 2000 | |
Loading volume (L) | ≤50 | ≤ 175 | ≤ 250 | ≤ 375 | ≤ 500 | ≤ 750 | ≤ 1000 | |
Rotary speed (r/min) | 3-13 | |||||||
Motor power (kw) | 0.75 | 1.1 | 1.5 | 2 | 3 | 3 | 4 | |
Rotary height (m) | 1.75 | 2.1 | 2.25 | 2.49 | 2.8 | 2.94 | 2.99 | |
Tank inner pressure (Mpa) | -0.1-0.15 | |||||||
Clip set pressure (Mpa) | ≤ 0.3 | |||||||
Working temp.(°C) | Inner tank ≤ 85 Clip set ≤ 140 | |||||||
Heating media | Steam, Hot water, Heat transfer oil | |||||||
Weight (kg) | 800 | 1100 | 1200 | 1500 | 2800 | 3300 | 3600 | |
Floor area (L*W) | 2160*800 | 2260*800 | 2350*800 | 2550*1000 | 2860*1300 | 3260*1400 | 3760*1800 |
Machine Picture:
