Main Usage
Suitable to the materials-drying for the lines of medicine , chemical , foodstuff, and electronics.
Specialty
1 Under constant temperature if the vacuity of drum is improved ,the drying speed can be shortened.
2 Under constant vacuity if the heating temperature is elevated ,it can accelerate the drying speed .
3 If both the vacuity and heating temperature is elevated ,the drying speed can be shortened greatly .
If a condenser is accepted , the vaporized agent in the target materials can be recollected by condenser , which is the normal drying facility ,If Model JZJS-70 liquid loop pump vacuum unit is Used , the condenser can be omitted to save energy and investment .
Technical Data
Model |
YZG-600 |
YZG-1000 |
YZG-1400 |
FZG-15 |
Inner size of drying box (mm |
Φ600×976 |
Φ1000×1527 |
Φ1400×2054 |
1500×1400×1220 |
Outer size of drying box (mm) |
1135×810×1020 |
1693×1190×1500 |
2386×1675×1920 |
1513×1924×2060 |
layer of dry rack |
4 |
6 |
8 |
8 |
Distance between layers (mm) |
81 |
102 |
102 |
122 |
Size of dry tray (mm) |
310×600×45 |
250×410×45 |
400×600×45 |
480×630×45 |
Number of dry tray |
4 |
24 |
32 |
32 |
Use press.inside of pipe (Mpa) |
≤0.784 |
|||
Use temperature of rack () |
-35150 |
|||
No load vacuum inside box (Pa) |
1330(10mmHg) |
|||
Packing
