Help CenterTraditional Chinese Medicine Sliced Medicinal Herbs Oven Dryer Trayer
Related Products
-
Pharmaceutical Square Vacuum DryerUS$ 3,000 - 20,000MOQ: 1 Set -
Oven Dry Trayer Machine for SaleUS$ 3,200 - 100,000MOQ: 1 Set
-
Hot-air Tray Dryer Oven MachineUS$ 5,000 - 15,000MOQ: 1 Set
-
Square Vacuum DryerUS$ 3,000 - 20,000MOQ: 1 Set
-
JB Series Stainless Steel Double Cone Rotary Vacuum Drier for SaleUS$ 5,000 - 20,000MOQ: 1 Set
Main Usage
This machine is widely applied for the heating and dehumidifying of raw materials and products in the lines of pharmacy ,chemical , foodstuff , light industry , heavy industry etc .
Specialty
Great part of hot wind is circulated in the oven with high thermal efficiency ,less energy consumption , The oven is equipped by the adjustable air-distributing plates to utilize the forced ventilating to dry the target materials evenly , The whole machine runs in stable condition ,low noise , self-control temperature , easy installing and maintaining ,and wide application.
Technical Data
Model&Specif. Tech. |
dry amount eachkg |
matched powerkw) |
steam expend (kg/h) |
heat dispelling area |
wind |
diff.in up & down temp. |
collo-cate tray |
Overall sizeL×W×Hmm |
Weight |
collo-cate pushcart |
JB-B-O |
50 |
0.45 |
10 |
10 |
3450 |
±2 |
24 |
1400×1200×2000 |
800 |
1 |
JB-B-I |
100 |
0.45 |
18 |
20 |
3450 |
±2 |
48 |
2300×1200×2000 |
1500 |
2 |
JB-B-II |
200 |
0.9 |
36 |
40 |
6900 |
±2 |
96 |
2300×2200×2000 |
1800 |
4 |
JB-B-III |
300 |
1.35 |
54 |
80 |
10350 |
±2 |
144 |
2300×3220×2000 |
2200 |
6 |
JB-B-IV |
400 |
1.8 |
72 |
100 |
13800 |
±2 |
192 |
4460×2200×2290 |
2800 |
8 |
If you want to send inquriy to me, could you please tell me?
1 What material you want to dry?
2 What capacity you expect ? (kg/h)
3 What voltage you want? For example, 380V 50hz 3p; 440V 60Hz,3p; 220V...
(We only provide 3P, because our machines are all for industrial use,not for family.)
Then our communication will be more efficient.
