Help CenterThree Layers Belt Drying Machine
Related Products
Specifications
DWC series three belt drying machine is a widely used drying machine, enjoy compact structure, high efficiency, dry heat effectWorking Methods
DWC series multilayer belt drying machine is the company to slice, roll, d shape, and design of granular materials for drying machine, this equipment has three layers (upper, middle and down ), each section according to the characteristics of the material can be independent drying temperature adjustment.
Its working principle: the material by hopper limit control, is evenly spread in the nets , by the transmission motor drive to send to the top, and then uniform motion in the dry machines , and step by step to sports.
The cold wind into by a head of the axial flow fan , after baffle plate ZhenLiu by, under each layer nets are equipped with heater, the cold wind was constantly heating by the gradient , and then through the material layer,then mass transfer, heat transfer, make the material contains water rapidly vaporized, evaporation, when to the top floor has become saturated wet air, in the function of exhaust fan, outdoor expelled.
Material movement explan
The machine has three layer structure, and the material into hopper again by conveyor mesh belt up to the top into dry machine, with the upper nets take exercise materials to the machine at the other end, and along the block material down to the next layer board; Material with the layer again with dry the body through the network, to the other side along the block material board down to the bottom, with most lower level nets take exercise to machine the other end the material!
