Specifications
This Vibrating Screw Charging Machine can convey sorts of material. Combined with the package-machine of our company, it can do material situation tracing. Also can be used separately. Complete machine made in stainless steel, except for the electrical machine, gearing, and the framework.
Characteristics:
lVibrating screw feeding machine is composed of double motor, feeding motor, vibrating motor and each switch control.
lHopper is adjustable and vibrational which make material to be flowing easily. It is good to material.
lHopper is separate from twisting shaft. Structure is reasonable and easily loading and unloading.
lCharacteristic dustproof, bearing won’t be polluted by the dust and powder.
lTo cleanup scrapped materials conveniently and design the machine to be: Discharging the material reversally, storing materials at the bottom of hopper pipe, taking out the whole screw.
Optional Component:
Standard control box
Safety Net
Vibration Sieve
Hopper cover
Dust cover
Blender for anti-bridge
Technical Data:
Model |
JB-3 |
JB-5 |
JB-6 |
JB-8 |
JB-10 |
Capacity |
3 m³/h |
5 m³/h |
6 m³/h |
8 m³/h |
12 m³/h |
Speed |
20-140 |
20-140 |
20-140 |
20-140 |
20-140 |
Inverter |
optional |
optional |
optional |
optional |
optional |
Pipe Diameter |
φ114mm |
φ141mm |
φ159mm |
φ168mm |
Φ219mm |
Main power |
0.77 KW |
1.57 KW |
2.26 KW |
3.06 KW |
4.06 KW |
Power |
1.52 KW |
2.22 KW |
3.02 KW |
4.02 KW |
5.57 KW |
Weight |
130 kg |
170 kg |
200 kg |
220 kg |
270 kg |
Hopper volume |
200 L |
200 L |
200 L |
200 L |
200 L |
CE Certificate
If you want to send inquriy to me, could you please tell me?
1 What material you want to convey?
2 What capacity you expect ? (kg/h)
3 What voltage you want? For example, 380V 50hz 3p; 440V 60Hz,3p; 220V...
(We only provide 3P, because our machines are all for industrial use,not for family.)
Then our communication will be more efficient.
