mini round hay balers grass bale machine

Specifications

agricultural walking type bundle strapping machine
Matched power18-50hp
Walking type Wheel type
Collection width 800mm

 Farm tractor mounted hydraulic hay baler in meadow ranch

   The baler machine is a new type agricultural machine developed by our company, it can bundle up all kinds of wheat, straw and pasture.

Superiority:

(1) Pthe environment pollution by the farmers burning straw perch;

(2) Increasing the peasant income, the finished grass bundling are easy to sale;

(3) Reasonable using the resource, the straw after bundling can be well used, example processing forage of livestock and fowls.



Features

1 Reasonable structure

2 Tractor driven PTO

3 Automatic leading rope, taking straw, bundling and cutting rope when it is bundling the straw

4 Can change the rope circle and bundling density to prevent the grass bundle scatter and untidy.

5 Be mainly constituted  by collection standing grain machine, bale grass roller, chain wheel transmission mechanism, rope box



Technical Data



MODEL	9YK-8050
Matched power	18~50 hp
Drive type	Rear PTO for Tractor
Dimension( L ×W×H)	1235×1490×1575(mm)
The weight of Machine	420 Kg
Working Width	800mm
Working Speed	1~1.5 m/ s
Weight of grass bundle	15~20Kg
Dimension of grass bundle	Φ500×800(mm)
Bundle type	Hydraulic pressure opening by handle
Packing Dimension	Iran frame (1100×1100×1100mm)
